    PC Control Computerized Mechanical Tensile Test Equipment Materials Testing Machines

    Ask Lasest Price
    Brand Name : Haida
    Model Number : HD-B603
    Certification : CE,,ISO
    Price : Negotiation
    Payment Terms : L/C, T/T, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 75 Piece / Pieces Per Month
    Delivery Time : 15 Days After Order
    • Product Details
    • Company Profile

    PC Control Computerized Mechanical Tensile Test Equipment Materials Testing Machines

    PC Control Computerized Mechanical Tensile Test Equipment Materials Testing Machines


    PC control computerized electronic universal Tensile Test Equipment is widely used in wires & cables, hardware, metal, rubber, footwear, leather, apparel, fabric, tape paper products, pharmacy and so on, for tensile strength, tear resistance, peel strength, bend strength, shear force , ect with different fixtures according to national and international standards customer required.



    2.Design Standards:
    ASTM D903; GB/T16491; GB/T1040; GB/T8808; GB13022; GB/T 2790/2791/2792; CNS-11888; JIS-K6854; PSTC-7



    3.Theory:
    50KN PC control computerized electronic universal Tensile Test Equipment adopts the material tensile meter,use the motor to make displacement of the fixture. Place the fixture with sample between the upper and lower fixture,and the upper load cell with sensor the tensile strength, and convert the strength into voltage sign and output to the display screen. And the strength value will be displayed automatically.



    4.Main Technical Parameter:

    Items

    Specification

    Sensor

    Celtron load cell

    Capacity

    1000,2000,3000,5000kg

    Unit Switchover

    G, KG, N, LB

    Display Device

    PC

    Resolution

    1/250,000

    Accuracy

    ±0.5%

    Max. Stroke

    1000mm (including fixture)

    Test Speed

    0.1-300mm/min (adjustable )

    Motor

    Panasonic Servo Motor

    Screw

    High Precise Ball Screw

    Elongation Accuracy

    0.001mm

    Power

    AC220V, 50HZ

    Weight

    Approx.250kg

    Accessories

    One set tensile clamp,one set Lenovo computer, one piece English software CD, one piece operation video CD, one piece English user manual




    5.Product Features:
    . Motor system: Panasonic servo motor +Servo driver +High precise ball screw (Taiwan)
    . Control system: a, computer control with TM2101 software; b, Back to origin automatically after the test, c, store data automatically or by manual operation
    . User can set parameters of product material such as length, width, thickness, radius, area and so on.
    . Many languages random switching: Simplified Chinese, Traditional Chinese, and English.



    6.Images:




    HD-B604B-S Universal Test Machine.pdf
