Fluke 5730A High Performance Multifunction Calibrator

Name: Fluke 5730A High Performance Multifunction Calibrator
Brand: Fluke
Price: 1 USD

Add to Cart

Key features

Calibrate up to long-scale 8.5 digit digital multimeters and RF voltmeters with wideband option.
Improved AC voltage, AC current, and resistance specifications for increased test uncertainty ratios (TURs).
6.5-inch VGA touchscreen, a full-color interface, and Visual Connection Management™ output terminals
Full Met/CAL® compatibility with 5700A and 5720A procedures

Technical Specifications
Voltage DC	Range	0 to ±1100 V
	Best 1 Year, 95% Specification	3.5 ppm + 2.5 µV
Voltage AC	Range	22 µV to 1100V;10 Hz to 1 MHz
	Best 1 Year, 95% Specification:	42 ppm + 8 µV
Resistance	Range	0 to 100 MΩ, 18 values in x1 and x1.9
	Best 1 Year, 95% Specification	6.5 ppm
Current DC	Range	0 to ±2.2A (0 to ±11A with 5725A; 0 to ±100 A with 52120A)
	Best 1 Year, 95% Specification	35 ppm + 7 nA
Current AC	Range	9 µA to 2.2A, 10 Hz to 10 kHz (9 µA to ±11A with 5725A; 9 µA to ± 120 A with 52120A)
	Best 1 Year, 95% Specification	103 ppm + 8 nA
Wideband ac Voltage option	Range	300 µV to 3.5V;10 Hz to 50 MHz
	Best 1 Year, 99% Specification	0.4% + 500 µV
