Two Roller Mixing Mill Machine, Mixing Mill Machine XK-230
| Item | XK-160 | XK-250 | XK-360 | XK-400 | XK-450 | XK-550 | XK-560 | XK-660 | XK-710 |
| Roll diameter | mm | 160 | 250 | 360 | 400 | 450 | 550 | 560/510 | 660 | 710 |
| Roll working length |
| 320 | 620 | 900 | 1000 | 1200 | 1500 | 1530 | 2130 | 2200 |
| Front roll linear speed | r/min | 9 | 16.3 | 16.7 | 19.3 | 21.8 | 22.5 | 27.2 | 28 | 31.9 |
| Speed ratio of rolls |
| 1: 1.4 | 1: 1.1 | 1: 1.3 | 1: 1.3 | 1: 1.3 | 1: 1.2 | 1: 1.2 | 1: 1.2 | 1: 1.5 |
| Max roll space | mm | 4.5 | 8 | 10 | 10 | 12 | 16 | 15 | 0.5-15 | 0.5-15 |
| Compound feeding capacity | kg | 1-2 | 10-15 | 20-25 | 18-35 | 50 | 50-65 | 50-65 | 165 | 190 |
| Motor power | kW | 5.5 | 18.5 | 30 | 45 | 55 | 110 | 90 | 240 | 280 |
| Dimensions(L× W× H) |
|
|
|
|
|
|
|
|
|
|
| L | mm | 1133 | 2722 | 4200 | 4920 | 5405 | 6646 | 6270 | 7280 | 8185 |
| W | mm | 920 | 1115 | 1780 | 1780 | 1740 | 2736 | 2282 | 3400 | 3910 |
| H | mm | 1394 | 1345 | 1760 | 1800 | 1790 | 2105 | 2000 | 2530 | 2270 |
| Gross weight | T | ~2 | ~3.2 | ~6.5 | ~8 | ~11.4 | ~22 | ~22.5 | ~49 | ~51 |
Salient Features:1. Superior Mixing Performance.
2. Low Operating Cost with High Productivity.
3. Compact Construction, maximum Floor Utilization.
4. Latest Technology Update, Meets Current World Standards.
5. Maintenance Free.
6. Reliable and Experienced Service Back Up.
7. Easy to Install & Ready to Run.
8. No continuous Lubrication hence heavy saving on lubrication
cost, wear & tear and maintenance.
9. Auto reversing electric Panel.
10. Simple & easy maintenance.
Test Before Delivery:In order to save time and cost for customers, we produced rubber
mixing mill at the factory wires between the motor and the control
cabinet already connected, the customer's only need to connect the
wires to the outside the control cabinet. After Rubber Mixing Mill
complete installation will have the load test 4-6 hours to reduce
debugging time and cost.
FAQ1. Delivery time of the rubber machines?This is specially designed machine according to your specific
requirement.
From engineer designing to production completion, it needs about 25
to 35 days.
2. What does your factory do regarding quality control?We pay much more importance to quality control from the very
beginning to the end of production.
Every machine will be fully assembled and carefully tested before
shipment.
3. What's the machine quality guarantee?Quality guarantee time is one year.We choose world famous brand
components to keep our machine in perfect working condition.
4. Are you able to give installation and commissioning overseas?
How long time will it take?Yes, we can supply overseas service and technical support but
customer needs to pay for the cost of the installation.
Small machine usually takes within 2~3 days.
Big plant usually takes about 30 days.
5. How can I trust you to deliver the right machine as I ordered?We will absolutely deliver a good quality machine as we discussed
and confirmed in the order.
The core of our company culture is innovation, quality, integrity
and efficiency. Also we have had much good cooperation with world
famous rubber production manufacturers. If you come to our factory,
we can show you're the user around us.
6. How can we go to your side?We are located in Qingdao City, Shandong province, China. The name
of airport is Qingdao Liuting airport.
We will pick up you at the airport.
In addition, our machineries have exported to America, Mexico,
India, Vietnam, South Africa, Singapore, Malaysia, Indonisia,
Australia, Sri Lanka and many other countries.
If you interested in our products mentioned above. Kindly let us
know by return email. Then I will supply you with further
information.
welcome to visit our factory!
