    7 Pin 1.27mm PCB Female Socket Connector, Right Angle SMT Board Interface for High Speed Signal Transmission, Custom Wire Harness, Automotive and Industrial Electronic Power Systems

    Product Description

    This compact PCB female connector uses a 1.00 mm fine pitch to deliver high-density routing on crowded boards while maintaining reliable electrical performance. Multi-pin SMT terminals provide stable signal and low contact resistance for data and control lines in compact electronic assemblies.

    The connector housing is molded from high-temperature, flame-retardant thermoplastic, compatible with standard reflow processes. Precision-formed copper-alloy contacts with tin or selective gold plating ensure long-term durability, stable mating cycles and robust signal integrity in vibration-prone environments. OEM/ODM customization is available for different pin counts, keying structures, plating options and matched cable or wire harness solutions.



    Connector typePCB female connector, single row, multi-pin
    Pitch1.00 mm (other pitches customizable on request)
    Number of positions6–10 pins optional, custom pin counts available
    Mounting styleSurface-mount (SMT) on PCB
    OrientationRight-angle, low-profile
    Contact typeFemale signal terminals
    Contact materialPhosphor bronze or equivalent high-strength copper alloy
    Contact platingTin or selective gold over nickel, optimized for low contact resistance
    Housing materialHigh-temperature thermoplastic, UL94V-0, halogen-free option
    Rated currentup to 1.0 A per pin (depending on layout and ambient temperature)
    Rated voltageup to 50 VAC / 50 VDC
    Insulation resistance≥ 1,000 MΩ at 500 VDC
    Contact resistance≤ 30 mΩ (initial)
    Dielectric withstand250 VAC, 1 minute
    Operating temperature−40 °C to +105 °C
    PCB terminationSMT solder pads, suitable for automated reflow
    PackagingTape & reel or tray for automatic pick-and-place
    ComplianceRoHS, HF, REACH compliant; automotive/industrial grade available
    CustomizationSpecial pin mapping, keying, plating thickness and wire harness assemblies

    Applications

    Control boards and interface modules in industrial and factory automation equipment

    Automotive electronic control units, infotainment systems and body control modules

    Server and storage transmission boards, communication base-stations and network devices

    Consumer and IoT electronics requiring compact board-to-board or board-to-cable interconnection

    Power and low-voltage signal distribution within battery management or monitoring PCBs

    Precautions

    Design PCB pads and solder mask strictly according to the recommended land pattern to ensure proper solder fillet and coplanarity.

    Avoid exceeding specified current and voltage ratings; derate appropriately at elevated ambient temperatures.

    Follow standard SMT reflow temperature profiles suitable for high-temperature thermoplastic; avoid multiple reflow cycles beyond connector specifications.

    Keep contacts free from flux residues, dust or oil; contamination may increase contact resistance or reduce insulation performance.

    When used in high-vibration automotive or server applications, ensure mating connector or cable assembly includes suitable retention features and strain relief.

    Store connectors in their original packaging, in a dry environment, to prevent terminal oxidation before assembly.
