5 10 20 50 100 200 300 400 500 Micron Stainless Steel or Brass Wire Mesh Lab Test Sieve

Quick details of mesh Lab Test Sieve

• Sieve Diameter: 100 mm - 600 mm
• Sieve Depth H1: 40, 50 ,60, 80 or 100 mm
• Woven Wire Cloth: 28 µm to 2.36 mm
• Square Apertures: 0.028mm to 2.36 mm
• Material to be Sieved: Powders, Aggregates, Suspensions, Seeds, etc.
• Mesh/Screen: The sieve is the most technical part of the laboratory test sieves. The most commonly used mesh type is stainless steel woven wire mesh.
• Frame: Frames are circular metal rings that hold the grid in place.100mm, 200mm and 300mm are standard sizes. The screen frame can be made of stainless steel or brass.
• Skirt: The main function of the skirt is to allow the test sieves to be stacked without tipping over.

Description of Mesh Lab Test Sieve

Woven Wire Cloth Test Sieves apertures are suitable for all types of screening tasks: hand sieving, conventional screening analysis of aggregates, dry- and wet-sieving. Our precision-aperture technology and rigorous optical inspections using modern Image Dimension Measurement Systems guarantees our sieves meet the highest criteria of national and international standards .

Huihao also offers individual sieve solutions tailored to the unique requirements of your sieving task. Special test sieves with a pore size of less than 20 μm can be used, but it should be understood that the finer the sieve, the easier it is for certain types of solid particles to block or block the pore size. However, special techniques can be used to perform "micro" sieving as small as 5 μm.

Specification of Aperture and Mesh Conversion
