    150KVA Three Phase Pad Mounted Transformer 12.47KV To 208V Power Distribution Transformer with DOE 2016 Standards and DYN1 Vector Group

    Ask Lasest Price
    Brand Name : WINLEY
    Model Number : ZGS-150/12.47
    Certification : UL/cUL,CE,ISO
    Price : $5000-$150000
    Payment Terms : T/T
    Supply Ability : 1000set/month
    Delivery Time : 30days
    • Product Details
    • Company Profile

    150KVA Three Phase Pad Mounted Transformer 12.47KV To 208V Power Distribution Transformer with DOE 2016 Standards and DYN1 Vector Group

    150KVA Three Phase Pad Mounted Transformer Oil Immersed 12.47KV To 208V power distribution transformer 304 SS



    WINLEY three-phase pad-mounted transformers combine advanced design, proven protection, high efficiency and flexible configurations to reduce total cost of ownership while delivering stable, high-quality power. With broad standards compliance, UL/cUL certification, global delivery experience and rapid lead times, WINLEY is a reliable partner for distribution transformer projects worldwide.



    Most transformer enclosures are made of mild steel with a powder-coated paint finish. These enclosures hold up well in normal service conditions. But they can rust rapidly in corrosive environments.304 stainless steel meets the needs of most corrosive environments, Ideally, this protects the unit for roughly 50 years.



    Technical drawings


    The three phase pad mounted transformer immerses the load switch and fuse on the high voltage side of the transformer with the core and windings of the transformer in the same oil tank, has the advantages of advanced structure, reliable performance, energy saving and consumption reduction, flexible use, strong adaptability, and economical advantages.



    Main data


    Transformer TypePad Mounted, Compartmental-Type
    Transformer ConfigurationLiquid Filled Pad Mounted
    Transformer Feed TypeRadial Feed
    PhaseThree Phase
    Capacity150 KVA
    Vector GroupDYN1
    Primary Voltage12470V
    Secondary Voltage208Y/120
    Frequency60 Hz
    Temperature Rise65°C
    Insulation RatingClass E Insulation - 120°C, 248°F
    Cooling ClassONAN; Self-Cooled
    Efficiency Standard(s)Meets DOE 2016 Standards, Meets CSA Standards Meets ANSI/IEEE Standards
    Winding MaterialCopper
    Tank Material304 Stainless Steel


    Application


    • Digital Currency Mining – Provides stable power for remote mining farms, ensuring efficient operations.
    • Data Centers – Converts high-voltage power for stable electricity and backup during outages.
    • Renewable Energy – Transmits solar/wind power to the grid and supports battery storage.
    • Commercial Buildings – Powers lighting, HVAC, and IT systems with backup for outages.
    • Transport Hubs – Ensures electricity for airports, train stations, and ports (lighting, signals, cranes).
    • Agriculture – Distributes power for farm equipment, irrigation, and storage, boosting productivity.
    • Industry – Reliable power for machines, automation, and cost-efficient production.
    • Schools & Hospitals – Supports critical infrastructure, research, and medical equipment



    Specification


    Rated Power
    (KVA)
    High Voltage
    (KV)
    Low Voltage
    (V)
    No-load Loss
    (W)
    On-load Loss
    (W)
    Height
    (mm)
    Depth
    (mm)
    Width
    (mm)
    Weight
    (kg)
    Weight
    (Lbs)
    75KVA34.5KV
    4.160KV
    12.47KV
    13.2KV
    13.8KV
    24940GrdY/14400
    1247Grdy/7200
    4160GrdY/2400
    or others
    277V
    347V
    480V
    600V
    120/240V
    208GrdY/120
    415GrdY/240
    480GrdY/277
    600Y/347
    1801250143091019306451422
    150KVA2802200153098015109892180
    300KVA480365016801080166014153119
    500KVA680510017901160181019054200
    750KVA980750020301300203027556074
    1000KVA11501030018541549165132357132
    1500KVA164014500215015702210583512864
    2000KVA216020645222016002380643014175
    2500KVA268023786233016503070886519544
    3000KVA3300303002460185032601130024912
    3735KVA4125378752680206040801440031746


    Production process
