ISO9001 IATF16949 CE Certified K Type Thermocouple Cable with High Temperature Resistance and Customizable Length

    Buy cheap ISO9001 IATF16949 CE Certified K Type Thermocouple Cable with High Temperature Resistance and Customizable Length from wholesalers

    Buy cheap ISO9001 IATF16949 CE Certified K Type Thermocouple Cable with High Temperature Resistance and Customizable Length from wholesalers
    • Buy cheap ISO9001 IATF16949 CE Certified K Type Thermocouple Cable with High Temperature Resistance and Customizable Length from wholesalers

    ISO9001 IATF16949 CE Certified K Type Thermocouple Cable with High Temperature Resistance and Customizable Length

    Ask Lasest Price
    Brand Name : LEADKIN
    Model Number : LK-K
    Certification : ISO9001, IATF16949, CE
    Price : USD 0.35-6.5/M
    Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram
    Supply Ability : 1,000,000M/year
    Delivery Time : 2-7 working days
    • Product Details
    • Company Profile

    ISO9001 IATF16949 CE Certified K Type Thermocouple Cable with High Temperature Resistance and Customizable Length

    Versatile K Type Thermocouple Cable for Accurate Temperature Detection and Monitoring
    Quick Details
    • Type: K/N/E/J/T/S/R/B
    • Place of Origin: Zhejiang, China (Mainland)
    • Accuracy: I-0.4%t, II-0.75%t, III-1.5%t
    • Core number: 2,3,4,6
    • Inorganic mineral insulating lead material: Ni, Cu
    • Insulator: 99.6% high purity MgO
    • Certificate: ISO9001, IATF16949, CE
    • Application: connecting with thermocouple and instrument machine
    • Sheath material: 0Cr18Ni10Ti, SS304S, SS316L, SS316, Cu
    • Sheath Dia(mm): φ3.0, φ4.0, φ6.0, φ8.0
    Type for Sheath Wire Type K
    Product NameCodeTypeSheath MaterialOutside Dia.Temperature
    NiCr-NiSi /NiCr-NiAlKKKSS304 SS3160.5-1.0400
    1.5-3.2600
    4.0-8.0800
    SS310 Inconel6000.5-1.0500
    1.5-3.2800
    4.0-6.4900
    8.0-12.71000
    Different temperature measuring media and service conditions have an impact on the service life and temperature range of armored thermocouples. The data in the table is only recommended data.
    Accuracy for Sheath Wire Type K
    TypeClass IClass II
    K±1.5℃ (-40~375℃)±2.5℃ (-40~375℃)
    ±0.4% (375℃-1000℃)±0.75% (375℃-1000℃)
    N±1.5℃ (-40~375℃)±2.5℃ (-40~375℃)
    ±0.4% (375℃-1000℃)±0.75% (375℃-1000℃)
    E±1.5℃ (-40~375℃)±2.5℃ (-40~375℃)
    ±0.4% (375℃-800℃)±0.75% (375℃-800℃)
    J±1.5℃ (-40~375℃)±2.5℃ (-40~375℃)
    ±0.4% (375℃-800℃)±0.75% (375℃-800℃)
    T±0.5℃ (-40~125℃)±1.0℃ (-40~125℃)
    ±0.4% (125℃-350℃)±0.75% (125℃-350℃)
    S±1.0℃ (0-1100℃)±1.5℃ (0-1100℃)
    Product Description
    • The Mineral-Insulated Thermocouple Wiring is available in different sizes, ranging from 0.5mm to 4.0mm, and can measure temperatures up to 1200°C. The conductor type can be either solid or stranded, depending on application requirements.
    • The mineral insulation provides excellent electrical insulation and mechanical protection, ensuring durability and reliability. The stainless steel sheath offers resistance to corrosion and high temperatures, making it ideal for harsh environments.
    • Available with different connector types including screw, plug, and socket, selected based on application requirements. Screw connectors suit frequent connections, while plug and socket types are ideal for permanent installations.
    • Highly reliable and accurate for industrial applications including chemical processing, food processing, pharmaceuticals, and research where precision is essential.
    Applications
    RTD and Thermocouple Sensors Constructed Using MI Cable are Used Extensively in Various Applications:
    • Solid waste incinerators
    • Sintering powdered metals
    • Firing ceramic materials
    • Gas or oil fired furnaces
    • Fuel fired heat exchangers
    • Box furnaces
    • Nuclear or hydrocarbon based energy plants
    Product Pictures
    Versatile K Type Thermocouple Cable product photo
    Company Information
    A. Main Products
    Leadkin main products display Leadkin product line showcase
    B. Package
    We add heat shrink tubing and plastic film to ensure high insulated resistance. Each coil cable includes marking notes, pass card, and test report.
    Thermocouple cable packaging
    C. MI Cable Production Line
    We maintain high-quality professional products with advanced production lines and equipment. All products comply with international quality standards and are appreciated in global markets. We continuously update products and improve production systems to meet increasing market demands.
    MI Cable production line at Leadkin facility
    Support and Services
    Our Mineral Insulated Thermocouple Cables provide accurate temperature measurements in high-temperature environments with various customization options:
    • Selection guidance for thermocouple type, sheath material, and insulation material
    • Assistance with cable installation and maintenance
    • Troubleshooting and problem-solving
    • Repair and warranty services
    Our expert team ensures customer satisfaction with reliable temperature measurement solutions.
    Order Notice
    1. Accurate quotation
    2. Confirm price, trade terms, lead time, payment terms
    3. Receive Proforma Invoice with LEADKIN seal
    4. Arrange deposit payment and send bank slip
    5. Production updates with photos showing your products in production line
    6. Final production photos before shipping
    7. Make balance payment and receive tracking information
    8. Complete order when goods are received satisfactorily
    9. Provide feedback on quality, service, and market suggestions
