    CNC Multi Axis Turning Milling Center , 2 Axis CNC Machine Center For Medical Devices

    Ask Lasest Price
    Brand Name : Lishang Precision Machinery
    Model Number : LS-6146/6146D
    Certification : CE ISO
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 500/month
    Delivery Time : 15-30days
    • Product Details
    • Company Profile

    CNC Multi Axis Turning Milling Center , 2 Axis CNC Machine Center For Medical Devices

    High Precision Cnc LS-6146/6146D Slant-bed Turning Lathe 2 Axis Machining Center


    It is a high-end CNC equipment designed for high-precision and high-efficiency metal processing. The 6146 series machine tools adopt a 45-degree inclined bed structure, combined with a high-rigidity casting process and a precision drive system. It is widely used in batch automated processing of shafts, discs and other parts, and can meet the strict requirements of aerospace, automotive parts, precision instruments and other industries for processing accuracy and production efficiency.


    Product specification



    Capacity


    Maximum rotation diameter on the bedφ400mm
    wing over cross slide300mm
    Max turning diameter300mm
    Max.turning length200mm
    SpindleSpindle speedXKC7530A/C:50~4500rpm
    Spindle through hole diameterΦ56mm
    Max.diameter of barsφ45mm(Chuck/Chuck)/φ45mm(Collet/Collt)
    Main motorXKC7540A/C:11/15KW
    TurretNumber of stations12
    Tool size20×20/φ32mm
    Tail stocktailstock dia90 m m
    tails tock quill travel90mm
    Axescenter taperMorse NO.5 high precision rotary top
    X Travel X450mm
    Z Travel Z400mm
    (X/Z) Rapid feed X/Z24m/min
    (X/Z)Feed motorsX/Z Servo 1.8/2.5KW
    7640C)Min.control angle0.001°
    OthersHollow hydraulic chuck8"
    Rotating hydraulic cylinder6"
    Required electric power15KVA
    Overall dimension2700X1650X1780
    Mass of machine( About ) 3 5 0 0 K g

    Product Feature

    1. High spindle configuration:Japanese ultra-high precision special spindle bearings,Spindle runout ≤ 3μm that achieve high speed and stability
    2. High spindle efficiency:The maximum spindle speed of the machine tool is 4500 rpm, and the X and Z axis fast feed can reach 24meters per minute. It can be equipped with an automatic feeder to achieve high-speed and efficient automated processing.
    3. CNC system:6146/6146D adopts FANUC numerical control system,Ensure quick command response, reliable operation and reduce operational difficulty.
    4. Perfect base, ultra-high rigidity. Wear-resistant and durable Specially designed 45-degree tilt angle for easy waste discharge Humanized design.
    5. High-speed, high-precision hydraulic rotary cylinder, combined with precision chuck and high-rigidity power chuck, significantly improves the powerful cutting ability of tough materials and meets high-strength processing requirements.
    6. Simple operation, fully automatic, time-saving and labor-saving

    Application

    1. Box parts:such as engine block, gearbox solve the problem of long processing cycle and difficult precision control of traditional machine tools
    2. Mould and disc sleeve parts:ensure mold forming quality through high-precision processing.
    3. Medical Devices and Aerospace:For example, complex precision surgical instruments, aerospace engine blades, etc.
    4. Metalworking:Milling, drilling, boring and other processing of metal materials such as aluminum alloy, steel, copper, etc.

    Sales service

    * Instructions for use: Online operating instructions and usage videos are available, and on-site training requires additional fees

    * Online guidance: Professional engineers provide online technical guidance to quickly solve customer problems

    * Provide 3-year warranty and lifetime technical support services


    What's your main products of your company?

    We mainly produce and sell various types of CNC machining centers, including vertical machining centers, gantry machining centers, horizontal machining centers, five-axis machining centers, profile machining centers, etc. We have our own factory to support customization and welcome factory inspections.

    What is the minimum order quantity?

    Minimum order is one piece but a 30% deposit is required.

    What payment methods are supported?

    T/T , Alibaba, Paypal, USDT, Alipay, Wechat, etc

    Which type shipment way ?

    About shipment that we have own deliver way like sea method or truck method .
