    Customized Power Supply Burn In Chamber with Wide Versatility and All-Round Aging for Comprehensive Testing

    Ask Lasest Price
    Brand Name : CPET
    Model Number : CP-301209
    Certification : CE,ROHS
    Price : ¥ 35800 yuan
    Payment Terms : T/T
    Supply Ability : 30sets/month
    Delivery Time : 30 work days
    • Product Details
    • Company Profile

    Customized Power Supply Burn In Chamber with Wide Versatility and All-Round Aging for Comprehensive Testing

    Power bank Smart Bluetooth Headset Charging Discharging Aging Test Machine


    It is widely applied to the aging of various power supplies, adapters, Bluetooth headphones, lamps and

    other products.


    Wide versatility

    One device can simultaneously test products of different powers, and different products can also be tested

    at the same time.


    Customized on demand
    According to the customer's needs, an aging cabinet that suits them can be customized


    Energy-saving feedback
    The independently developed energy-saving aging load can feed back the energy output by aging products

    for utilization, thereby saving 85% of the electricity consumption for aging.


    All-round aging

    Cooperate with aging monitoring software to monitor the product condition in real time


    Product parameters

    ModelCP-3011CP-3012CP-3013CP-3014
    Power of single channel65W/CH65W/CH65W/CH100W/CH
    Quantity of
    load channels
    192CH240CH384CH240CH
    Scope of load voltage2-100V2-100V2-100V3-20V
    Scope of load current0.05-5A/CH0.05-5A/CH0.05-5A/CH0.05-5A/CH
    Load precision0.05-5A/CH±(1%+0.1%FS)0.05-5A/CH±(1%+0.1%FS)
    Charge and discharge
    mode
    NONONOCC+CV Mode
    Load ModeCC+CV ModeCC+CV ModeCC+CV ModeCC+CV Mode
    Number for plies of
    product zone
    Single sideSingle sideSingle sideSingle side
    Height for plies of
    product zone(mm)
    170
    Width of
    products zone(mm)
    Series CC mode 340
    Temperature control of
    products zone
    Temperature control type of products zone: normal temperature-60℃
    Structure material of
    trolley
    Elaborately processed and produced with cold-rolled sheet
    Mode of main controlMonitoring software for burn-in of computer-monitoring type power
    Input mode of UUTMulti-purpose socket/speaker wire clip/custom design
    Interface mode of UUTConnecting fixture boards (with various specifications) for first choice/custom design
    Customizable fast charge
    function
    QC, PO, FCP, SCP, PPS, etc.
    External dimension2050*880*1900/custom design
