    P16NP (WI1609) Metal Ceramic Potentiometer 1w Fine-tuning Knob Potentiometer

    Ask Lasest Price
    Brand Name : Uchi
    Model Number : P16NP (WI1609)
    Certification : SMC
    Price : Negotiable
    Payment Terms : T/T,paypal, Western Union,MoneyGram
    Supply Ability : 50000000pcs per Month
    • Product Details
    • Company Profile

    P16NP (WI1609) Metal Ceramic Potentiometer 1w Fine-tuning Knob Potentiometer

    P16NP (WI1609) Metal Ceramic Potentiometer 1w Fine-tuning Knob Potentiometer

    The P16 is a revolutionary concept in panel mountedpotentiometers. This unique design consists of a knobdriving and incorporating a cermet potentiometer. Only themounting hardware and terminals are situated on the backside of the panel reducing to a minimum the requiredclearance.

    Product Features

    P16 - version for professional and industrial applications (cermet)1 W at 40 ℃
    PA16 - version for professional audio applications(conductive plastic)0.5 W at 40 ℃
    Compact (integrated)
    High dielectric strength: 2500 VRMs
    Fully sealed and panel sealed
    Metallic or plastic knob options
    Custom knob on reques

    Specification Parameters
    Electrical Characteristics
    Standard Resistance Range
    100 to 2 megohms(see standard resistance table)
    Resistance Tolerance
    ±10% std.(tighter tolerance available)
    Absolute Minimum Resistance
    1% or 10 ohms max.(whichever is greater)
    Contact Resistance Variation
    3% max.
    Insulation Resistance
    500 Vdc, 1000 megohms min.
    Dielectric Strength
    101.3 kPa 900 Vac 8.5 kPa 500 Vac
    Adjustment Angle
    265°nom.




    Environmental Characteristics
    Power Rating (200 volts max.)
    1 watt (70°C) , 0 watt (125°C)
    Temperature Range
    -55°C to +125°C
    Temperature Coefficient
    ±250×10-6/°C or ±100×10-6/°C
    Vibration
    98 m/s2, 1%ΔTR
    Shock
    490 m/s2, 1%ΔTR
    Load Life
    1,000 hours 1 watt @ 70°C (5%ΔTR)
    Rotational Life
    10000 cycles:(15%ΔTR; 6% ,CRV)

    Physical Characteristics
    Mechanical Angle
    305° nom.
    Torque
    (3.5~50)mN·m
    Stop Strength
    350 mN·m min.

    Product Size



    Application Areas

    P16NP metal ceramic rotary potentiometer applied to Network communication systems, Night vision goggles, Audio head set, communication, Remote controls, Hot air blowers, Spotlights for scenes, Air fan controls, Industrial dashboards, Variable frequency drives, Electric wheelchair




    Manufacturer Information
    We are a specialized factory with extensive experience in high-quality electronic component manufacturing:
    • Advanced production equipment
    • Professional R&D team
    • OEM/ODM capabilities
    • Strict quality control standards
    Manufacturing facility for electronic components production
    Shipping & Support
    We offer reliable global shipping solutions with comprehensive after-sales support:
    • Express Mail Service
    • DHL Express
    • UPS
    • FedEx
    Product packaging and shipping process overview
    Frequently Asked Questions
    Are you a factory or trading company?
    We are a factory offering direct pricing with professional technical support.
    Could you provide samples?
    Samples are available upon request after order placement.
    Can your product be customized?
    We accept OEM/ODM orders with flexible requirements.
    What is your delivery time?
    Delivery varies by quantity and model, with urgent requests accommodated when possible.
    Do you offer after-sales service?
    We provide comprehensive 24-hour support for all products.
    Quality P16NP (WI1609) Metal Ceramic Potentiometer 1w Fine-tuning Knob Potentiometer for sale
