| Media | Compressed air |
|---|
| Operating Temperature | -34 ... 50 °C, -29 ... 122 °F |
|---|
| Port Size | 3/8" ISO G |
|---|
| Drain Type | Manual |
|---|
| Filter Element | 5 μm |
|---|
| Maximum Inlet Pressure | 10 bar, 145 psi |
|---|
| Flow | 35 dm3/sec, 74 scfm |
|---|
| Materials - Body | Aluminum alloy |
|---|
| Materials - Bowl | Polycarbonate (PC) |
|---|
| Materials - Elastomers | Nitrile rubber (NBR), Chloroprene rubber (CR) |
|---|
| Materials - Filter Element | Polypropylene (PP) |
|---|
Product Description:
The NORGREN F73G and F74G air filters are designed with several key
features that enhance their performance and reliability. These
filters incorporate high-performance filter elements, which are
capable of effectively removing both solid particles and liquid
contaminants from compressed air systems. This ensures that the air
remains clean and suitable for various industrial applications.
One of the notable aspects of these air filters is the inclusion of
an automatic drain valve. This valve automatically expels the
accumulated condensate, significantly minimizing the need for
manual maintenance. As a result, the filters can operate
continuously and efficiently, providing consistent filtration
without frequent interruptions.
In terms of design, the filters are compact, making them ideal for
installations where space is limited. They also feature a
transparent bowl, which enables users to visually monitor the level
of condensate and assess the filter’s operational status at a
glance. This transparency helps in timely maintenance and ensures
the system is functioning properly.
Furthermore, the NORGREN F73G and F74G filters have a pressure
rating suitable for most industrial requirements, which adds to
their versatility. Their durable and robust housing guarantees
long-term stable operation, even in demanding environments.
Additionally, certain models offer different filtration accuracy
options, such as 5 microns or 0.3 microns, catering to various
application needs and ensuring optimal air quality.
Applications:
The NORGREN F73G and F74G air filters are specially engineered for
use in compressed air systems. These filters are widely applicable
across various industrial settings and are compatible with numerous
types of equipment, such as pneumatic tools, actuators, air
cylinders, valves, and other pneumatic components.
The primary purpose of these air filters is to eliminate solid
impurities, including dust and rust particles, as well as to remove
liquid water from the compressed air supply. By doing so, they
ensure that the air delivered is clean and dry, which is crucial
for maintaining the performance of the pneumatic system.
By protecting downstream pneumatic equipment from contaminants and
moisture, the NORGREN filters help prevent damage and wear. This
protection enhances the overall reliability of the system, lowers
maintenance expenses, and contributes to a longer operational
lifespan for the equipment involved.
Support and Services:
Our Pneumatic Filter Regulator Lubricator (FRL) units are designed
to ensure optimal performance and longevity of your pneumatic
systems by providing clean, regulated, and lubricated air supply.
For technical support, please ensure that your FRL is installed
according to the manufacturer’s guidelines, including correct flow
direction and pressure settings.
Troubleshooting common issues such as pressure drops, air leaks, or
insufficient lubrication typically involves checking for clogged
filters, verifying regulator settings, and ensuring the lubricator
reservoir is filled with the appropriate lubricant. Regular
maintenance is recommended to replace filters and drain accumulated
moisture to prevent system contamination and damage.
For service and maintenance, always depressurize the system before
disassembling the FRL unit. Use only manufacturer-approved
replacement parts and lubricants to maintain product integrity and
warranty coverage. Detailed service manuals and installation guides
are available to assist with routine maintenance and repairs.
Should you require further assistance beyond standard
troubleshooting and maintenance, our technical support team is
available to provide expert guidance on product application, system
integration, and advanced diagnostics to maximize the efficiency
and reliability of your pneumatic system.
