On/Off Grid Solar Inverter Pure Sine Wave Solar Inverter

Product Features:

1.Up to 200% oversizing allowed with 3 MPPTS

2.Support Ac coupled solarinput

3.Stackable up to 9 units

4.Four application modes

5.Remote configuration and upgrade

6.Support 40-64V Lithium or Lead-acid battery

Technical Parameters:

Italy

Introduction: Combining Italian elegance with advanced technology, the SP8KL and SP10KL inverters offer exceptional efficiency and compliance with European energy standards.

FAQs:

1. What is the power factor adjustment range? The power factor is adjustable from 0.8 leading to 0.8 lagging, ensuring optimal grid interaction.

2. Is the inverter certified for use in Italy? Yes, it meets CEI 0-21 and other relevant Italian standards.

3. How does it handle grid frequency variations? It adjusts to frequencies between 47–52Hz and 57–62Hz, complying with local requirements.

4. Does it support lithium batteries? Yes, it is compatible with modern lithium-ion batteries for efficient energy storage.

5. What is the max AC output apparent power? The SP10KL model delivers 11,000VA, catering to high-demand households.

6. Is it resistant to moisture? Yes, with an IP66 rating, it is ideal for Italy’s humid coastal regions.

7. Can it be monitored remotely? Yes, through Bluetooth and mobile apps, you can access real-time performance data.

8. What is the operational altitude limit? It functions efficiently functions efficiently up to 4,000 meters, suitable for Italy’s alpine areas.

9. Does it include insulation resistance detection? Yes, it ensures safe operation by detecting insulation faults.

10. Why should Italians invest in this inverter? Its sleek design, high efficiency, and compliance with strict European standards make it a premium choice for sustainable living.

Spain

Introduction: Optimized for Spain’s sunny climate and renewable energy goals, the SP8KL and SP10KL inverters deliver unmatched performance and reliability.

FAQs:

1. What is the startup voltage for the PV input? The inverter starts operating at 90V, ensuring efficiency even in low-light conditions.

2. Is it compatible with Spanish grid codes? Yes, it adheres to RD 244/2019 and other local regulations.

3. How efficient is the inverter during battery discharge? It achieves up to 93% efficiency, ensuring minimal energy loss.

4. Does it support lead-acid batteries? Yes, it works with both lithium-ion and lead-acid batteries.

5. What is the max AC output current? For the SP10KL, it delivers up to 52A, meeting the demands of Spanish households.

6. Is it easy to install? Yes, its wall-mountable design and compact dimensions simplify the process.

7. Does it include surge protection? Yes, it features DC Type II and AC Type II surge arresters.

8. Can it handle multiple PV configurations? Yes, with three independent MPPTs, it optimizes energy harvest from diverse setups.

9. What is the warranty period? You can opt for a 5-year or 10-year warranty for added confidence.

10. Why is it a great fit for Spain? Its ability to maximize solar energy, comply with local standards, and provide backup power makes it an excellent investment.

France

Introduction: Embodying French innovation, the SP8KL and SP10KL inverters offer superior efficiency and reliability for residential solar systems.

FAQs:

1. What is the THDV level for backup output? It remains below 3% at full load, ensuring clean power for sensitive appliances.

2. Is the inverter compliant with French grid requirements? Yes, it meets NF C15-100 and other relevant standards.

3. How does it perform in colder climates? It operates efficiently operates efficiently down to -23°C, making it suitable for France’s varied weather.

4. Does it support communication with energy management systems? Yes, it features CAN and RS485 interfaces for seamless integration.

5. What is the max battery discharge power? For the SP10KL, it reaches 14,000W, providing ample backup power.

6. **Is Is it protected against overcurrent? Yes, it includes AC overcurrent protection for enhanced safety.

7. Can it be used in historic buildings? Its compact and silent operation makes it ideal for preserving architectural integrity.

8. Does it include a DC switch? Yes, it features a built-in DC switch for easy maintenance.

9. What is the cooling mechanism? It uses fan cooling to maintain optimal performance during peak usage.

10. Why should French homeowners choose this inverter? Its high efficiency, compliance with local standards, and elegant design make it a standout choice for modern solar systems.

South Korea

Introduction: Designed for South Korea’s tech-savvy consumers and dense urban areas, the SP8KL and SP10KL inverters combine smart features with robust performance.

FAQs:

1. What is the max efficiency from PV to AC? It achieves up to 97% efficiency, ensuring maximum energy savings.

2. Is it compatible with Korean grid standards? Yes, it supports 220V/230V/240V and 60Hz frequencies.

3. How does it handle grid islanding situations? It includes anti-islanding protection to disconnect from the grid during outages.

4. Does it support lithium batteries popular in Korea? Yes, it is fully compatible with lithium-ion batteries.

5. What is the max PV input current per MPPT? It handles up to 32A, ensuring compatibility with high-capacity solar panels.

6. Is it easy to monitor via smartphone? Yes, it features Bluetooth and app connectivity for convenient tracking.

7. Can it operate in high-humidity conditions? Absolutely! It functions reliably in 0–100% relative humidity.

8. What is the weight of the SP10KL model? It weighs approximately 42kg, making it manageable for installation.

9. Does it include leakage current protection? Yes, it detects and prevents leakage currents for safety.

10. Why is it a top choice for Korean households? Its smart features, high efficiency, and compact design align perfectly with South Korea’s innovative energy landscape.

Russia

Introduction: Built to endure Russia’s harsh winters and vast territories, the SP8KL and SP10KL inverters deliver reliable solar energy conversion and backup power.

FAQs:

1. What is the operating temperature operating temperature range? It performs efficiently from -28°C to 58°C, ensuring year-round reliability.

2. Is it compatible with Russian grid voltages? Yes, it supports 220V/230V/240V, fitting local requirements.

3. How does it handle voltage fluctuations? With an adjustable grid voltage range of 145V–305V, it adapts to unstable grids.

4. Does it support lead-acid batteries? Yes, it is compatible with both lithium-ion and lead-acid batteries.

5. What is the max battery charging current? For the SP10KL, it reaches 215A, enabling fast recharge times.

6. Is it resistant to snow and ice? With an IP66 rating, it is fully protected against environmental elements.

7. Can it be used in remote areas? Yes, its wide MPPT voltage range and rugged build make it ideal for off-grid applications.

8. What certification does it hold? It complies with GOST-R and other Russian safety standards.

9. Does it include a display for local monitoring? Yes, it features an optional LCD display for easy access to system data.

10. Why should Russians invest in this inverter? Its ability to operate in extreme cold, high efficiency, and robust construction make it indispensable for energy security.

Saudi Arabia

Introduction: Engineered for Saudi Arabia’s intense heat and abundant sunshine, the SP8KL and SP10KL inverters offer unparalleled performance and durability.

FAQs:

1. What is the max PV input power? The SP10KL model supports up to 18,000W, maximizing solar energy utilization.

2. Is it suitable for desert conditions? Yes, with its high-temperature tolerance and dust-proof IP66 rating, it thrives in arid environments.

3. How does it perform during sandstorms? Its sealed design protects internal components from dust and debris.

4. Does it support lithium batteries? Yes, it is fully compatible with modern lithium-ion batteries.

5. What is the cooling method? It uses intelligent fan cooling to dissipate heat effectively.

6. Is it compatible with local grid standards? Yes, it aligns with Saudi Arabian grid codes for seamless integration.

7. Can it handle high-load appliances? With a peak apparent power of 24,000VA for 1 second, it manages surges effortlessly.

8. What is the warranty period? You can choose a 5-year or 10-year warranty for long-term assurance.

9. Does it include surge protection for electrical storms? Yes, it features DC Type II and AC Type II surge arresters.

10. Why is it ideal for Saudi households? Its high PV input capacity, resilience to extreme heat, and compliance with local standards make it a top-tier choice.
