    HZ10N10F2OCP 10 Gigabit Dual-Port OCP3.0 Network Card with PCI Express 3.0 x8 for High-Speed Server Applications


    HZ10N10F2OCP is a dual-port 10 Gigabit optical fiber network adapter with PCI Express 3.0 x8 bus interface and OCP3.0 standard, which is developed on the basis of domestic N10 chip scheme. N10 is a network controller chip with reconfigurable processor technology, high security and high cost performance. It has completely independent intellectual property rights and supports dual-port 40G, 2/4/8-port 10G interface and 8-port 1G network applications. This chip is mainly used in many network applications such as servers, network security devices, embedded systems, etc. Its functions are as follows:
    (1) realize the function of 40G/10G domestic universal network card chip;
    (2) With 40G password acceleration capability, the function of security controllable network card can be realized;
    (3) It has programmable ability to realize intelligent unloading of user network protocols.
    Among them, HZ10N10F2OCP adopts domestic N10G-X2 chip, which supports different access rates of 10G and 1G, and has fully integrated 10Gigabit Ethernet media access control (MAC) module and physical layer (PHY) module. Support IP/TCP, IP/UDP checksum unloading, as well as data packet filtering and redirection of MACVLANTCP_SYN, and support FC and PFC at the same time in data traffic support.

    controller
    Domestic N100 Gigabit Intelligent Network Controller
    transmission medium
    optical fibre
    form
    OCP3.0 SFF
    Optical fiber type
    10GBASE-SR,10GBASE-LR,10GBASE-Cu
    1GBASE-SR,1GBASE-LR,1GBASE-Cu
    Power consumption (Max)
    7W
    Port type
    Two 10G SFP+ connectors
    portrate
    1/10Gbps
    PCIe bus
    PCIE3.0 x8
    NCSI
    support
    Power supply
    OCP power supply
    dissipate heat
    Passive heat dissipation
    Working temperature
    0ºC~ 70ºC
    Working humidity
    10%~90%No condensation
    Storage temperature
    -40ºC~85ºC
    Storage humidity
    5%~95%No condensation
    meet a criterion
    IEEE 802.3z Gigabit Ethernet
    IEEE 802.3x Full Duplex and flow control
    IEEE 802.1Q VLAN
    IEEE 802.3ad
    IEEE 802.3az - Energy Efficient Ethernet (EEE)
    IEEE 802.1P
    IEEE 802.3ac
    IEEE 802.2
    Network characteristics
    Support RSS with a maximum of 256 queues.
    Support packet unloading, IP/TCP and IP/UDP checksum unloading; TSO/GRO/TCO/RCO support.
    Support packet filtering, and support packet filtering based on MAC/VLAN/TCP_SYN and quintuple.
    Support packet redirection, support packet redirection based on MAC/VLAN/TCP_SYN and quintuple.
    Support flow control mechanism and FC/PFC.
    Support PTP, support IEEE1588v2, and support data packet uploading with timestamp.
    Support encryption protection of data stream, and support secure transmission protocols such as IPSec and MACSec.
    Support virtual Ethernet bridge (VEB)
    Support VxLAN/NVRGE
    Support PXE
    Support sideband management
    Support QoS, and support the control of data flow according to the queue mechanism.
    Support jumbo frames with a maximum size of 9564 bytes, and capture 100% of all frames (including jumbo frames) from 64 to 9564
    bytes.
    Support VLAN, support QinQ
    Support IPV4/IPV6.
    Support on-chip TCAM (support 8192 quintuple (SIP/DIP/SPORT/DPORT/PROTO) searches, with 4096 entries for each 40G port).
