Structure as below:
Protective film→PE Paint Finish→Aluminum Skin →Adhesive
Layer→Polyethylene Core
Advantages of using aluminum composite panels:
Aluminum composite panels can give residential projects like
bungalows and private estates a modern outlook.Aside from their
aesthetic value,aluminum composite panels have numerous other
advantages.The folloing are the 6 benefits of using aluminum
composite panels.
1.It can easily be bent into different shapes.
Aluminum panels have the ability to be bent into a variety of
different complex shapes and have a higher elastic limit,which
allows homeowners of large houses to more effectively utilize all
of the space that is available to them .
2.It is lightweight.
An aluminum composite panels are constructed using aluminum and a
low-density plastic core material.In addition,these building
materials are quite lightweight,enabling construction workers to
install them without any difficulties.
3.Different hues and surface patterns to choose from
The layers of the aluminum-plastic panel can be colored in various
ways,and the design can be customized to fit any
application.Photocopying technology is also used to replicate
granite,wood grain,and metal patterns in a distinctive texture and
high-quality pattern design.
4.It is highly resistant to extreme weather.
The aluminum-plastic composite board uses metal and core thermal
composite technology,and the bonding is strong.Surface coatings are
made of various materials depending on the application enviroment
,with fluorocarbbon coating having superior weather resistance.
5.It has a high surface flatness.
Because of a continuous thermal composite production process,the
surface flatness of the aluminum-plastic composite is higher than
that of a single-material metal sheet ,particularly the large-sized
sheet material.
6.It has a reasonable price.
Pre-coating and continous thermal compounding and metal/core
material are used in manufacturing aluminum plastic composite
panels.It has a high production efficiency and a low raw material
cost,making it a material with good cost features compared to
common metal veneers.
Technical Parameters:
| Product name | pvdf aluminum composite panel acp |
| Panel size | 1220*2440mm |
| Pannel thickness | 3mm,4mm,5mm |
| Panel width | 1000mm,1220mm,1250mm,1500mm,1550mm |
| Pannel length | 1000m,1220mm,2440mm,3200mm,5000mm,5800mm |
| Aluminum thickness | 0.03-50mm |
| Coating | PVDF |
| PE Core | Fireproof PE Core,Unbreakable PE Core |
| Bending Strength | >85° |
| Applications | Architectural Cladding, Interior Design |
| Weight | Lightweight (3.8-4.5kg/㎡) |
| Warranty | 20 years |
How to process:
1.Store enough aluminum sheets and polyethylene plastic,and conduct
corresponding inspection and quality control
2.The aluminum sheet and plastic sanwich layer are hot press formed
to firmly bond them together and form the final panel product.
3.The completed ACP panels need to undergo strict quality
inspection to ensure that they meet industry standards.
4.After qualified ACP panels are packaged,they can be shipped to
customers or distributors.
Applications:
ACP sheet or Aluminium Composite Panel is a new-age cladding
material that's used for building front elevation (facades),
interiors, signage, modular kitchen and many more. It is available
in a wide range of colours and textures like wood, stone, sand, 3D
etc.
Support and Service:
Our PE Aluminum Composite Panel product comes with comprehensive
Product Technical Support and Services to assist you with any
inquiries or concerns you may have. Our team of experts is
dedicated to providing you with timely and efficient support to
ensure the optimal performance of our product. Whether you need
assistance with installation, maintenance, or troubleshooting, our
technical support team is here to help.
Packing and Shipping:
Product Packaging and Shipping:
The PE Aluminum Composite Panel is carefully packaged to ensure its
safe delivery to you. Each panel is wrapped in protective film and
then packed in sturdy cartons to prevent any damage during transit.
For shipping, we partner with reliable carriers to deliver your
order securely and on time. You can track your package using the
provided tracking number for peace of mind.
FAQ:
Q: What is the brand name of the PE Aluminum Composite Panel?
A: The brand name is Alushang.
Q: What is the model number of the PE Aluminum Composite Panel?
A: The model number is 1220*2440MM 4MM.
Q: What certifications does the PE Aluminum Composite Panel have?
A: The panel is certified by SGS and ISO.
Q: Where is the PE Aluminum Composite Panel manufactured?
A: The panel is manufactured in China.
Q: What is the minimum order quantity for the PE Aluminum Composite
Panel?
A: The minimum order quantity is 300 square meters
