    304 Stainless Steel Tank 2500Kva Three Phase Pad Mounted Transformer 12.47KV To 480V Power Distribution Transformer 304SS UL Listed

    Ask Lasest Price
    Brand Name : WINLEY
    Model Number : ZGS-2500/12.47
    Certification : UL/cUL,CE,ISO
    Price : $5000-$150000
    Payment Terms : T/T
    Supply Ability : 1000set/month
    Delivery Time : 30days
    • Product Details
    • Company Profile

    304 Stainless Steel Tank 2500Kva Three Phase Pad Mounted Transformer 12.47KV To 480V Power Distribution Transformer 304SS UL Listed

    304 Stainless Steel Tank 2500Kva Three Phase Pad Mounted Transformer 12.47KV To 480V Power Distribution Transformer 304SS UL Listed


    Overview


    Introducing Winley’s 2500 kVA pad‑mounted, loop‑feed transformer — engineered for reliable utility and industrial power distribution. Built to meet ANSI C57.12.00 standards and available for indoor or outdoor service, this model combines robust electrical performance with a corrosion‑resistant 304 stainless‑steel housing and full UL/cUL certification to ensure safety, durability, and code compliance.





    Main data


    No.ParticularsUnitSpecification
    1Type~pad mounted,loop feed
    2Rated capacitykVA2500
    3No. of Phase~3
    4Primary voltageV12470Y/7200
    5Primary termintion~15kV class, 200A well&insert with elbow
    6Secondary voltageV480
    7Secondary termintion~12-hole spade
    8Tapping type~off-circuit tapping
    9Tapping range%±2*2.5%
    10Cooling method~ONAN
    11Rated frequencyHz60
    12Vector group~YNd1
    13Insulation class~A
    14Temperature riseK65
    15Off-load lossW2670
    16On-load loss (85℃)W23400
    17Impedance%5.75~7.50
    18Winding material~Aluminum
    19Core material~silicon steel
    20Cooling materialmineral oil
    21Housing material~304 stainless steel
    22Service condition~indoor or outdoor
    23Dimensionmm2950*2165*1900
    24Weightkg5514
    25Sea levelM≤1000

    Technical drawings



    Benefits of 304 stainless steel fuel tanks


    • Corrosion resistance: 304 stainless steel resists rust and pitting from weather, salt, and urban pollution — ideal for outdoor pad‑mounted installations.
    • Mechanical strength: Robust enclosure withstands physical impacts and maintains structural integrity over time.
    • Low maintenance: Smooth stainless surfaces are easier to clean and require less surface treatment than painted carbon steel tanks.
    • Aesthetic and longevity: Keeps site appearance professional while extending service life and minimizing lifecycle costs.



    Why choose us


    WINLEY manufactures a full range of three-phase pad-mounted transformers with capacities from 45 kVA to 5500 kVA and voltages up to 34.5 kV. The products meet or exceed DOE 2016, IEEE/ANSI, CSA, IEC, NEMA and other standards. Additionally, WINLEY’s three-phase pad-mounted transformers are UL/cUL certified (Certificate Numbers: UL‑US‑2431836‑0, UL‑CA‑2423202‑0)



    Specification


    Rated Power
    (KVA)
    High Voltage
    (KV)
    Low Voltage
    (V)
    No-load Loss
    (W)
    On-load Loss
    (W)
    Height
    (mm)
    Depth
    (mm)
    Width
    (mm)
    Weight
    (kg)
    Weight
    (Lbs)
    75KVA34.5KV
    4.160KV
    12.47KV
    13.2KV
    13.8KV
    24940GrdY/14400
    1247Grdy/7200
    4160GrdY/2400
    or others
    277V
    347V
    480V
    600V
    120/240V
    208GrdY/120
    415GrdY/240
    480GrdY/277
    600Y/347
    1801250143091019306451422
    150KVA2802200153098015109892180
    300KVA480365016801080166014153119
    500KVA680510017901160181019054200
    750KVA980750020301300203027556074
    1000KVA11501030018541549165132357132
    1500KVA164014500215015702210583512864
    2000KVA216020645222016002380643014175
    2500KVA268023786233016503070886519544
    3000KVA3300303002460185032601130024912
    3735KVA4125378752680206040801440031746

    Production process
