    SJA1105QEL 5-Port Automotive Gigabit Ethernet Switch IC with 10/100/1000 Mbit/s and 1.8/2.5/3.3 V Operation

    SJA1105QEL Ethernet IC 5-Port Automotive Gigabit Ethernet Switch With AVB And TSN


    Product Description Of SJA1105QEL
    SJA1105QEL safe and secure automotive gigabit Ethernet switch family extends the capabilities of the SJA1105QEL switches with improved security-related features, extended interface options, and ISO 26262 ASIL-A compliance.
    SJA1105QEL is a 5-port automotive Ethernet switch supporting IEEE Audio Video Bridging (AVB) and Time-Sensitive Networking (TSN) standards. Each of the five ports can be individually configured to operate at 10/100/1000 Mbit/s. This feature provides the flexibility to connect any Fast/Gigabit/optical PHY or MCU/MPU to any of the ports.


    Specifications Of SJA1105QEL

    Protocol
    Ethernet
    Function
    Switch
    Interface
    SPI
    Standards
    IEEE 802.3
    Voltage - Supply
    1.65V ~ 3.6V
    Current - Supply
    3.5mA
    Operating Temperature
    -40°C ~ 125°C (TJ)
    Package / Case
    159-LFBGA
    Supplier Device Package
    159-LFBGA (12x12)
    Grade
    Automotive

    Features Of SJA1105QEL
    General features
    • 5-port store and forward architecture
    • Each port individually configurable for 10/100 Mbit/s when operated as MII/RMII and 10/100/1000 Mbit/s when operated as RGMII or SGMII
    • Independent I/O voltage domains: selectable 1.8/2.5/3.3 V operation for MII/RMII/RGMII; selectable 1.8/2.5/3.3 V for host interfacing; 1.2 V core voltage domains
    • Small footprint: LFBGA159 (12 mm × 12 mm) package
    • Automotive Grade 2 ambient operating temperature: -40 °C to +105 °C
    • Automotive product qualification in accordance with AEC-Q100 Rev-H
    • ISO-26262, ASIL-A

    Ethernet switching and AVB features
    • IEEE 802.3 compliant
    • 128 kB frame buffer
    • 1024 entry TCAM for collision-free MAC address learning
    • 2 kB frame length handling
    • IEEE 802.1Q defined tag support
    • 4096 VLANs supported
    • Egress tagging/untagging on a per-VLAN basis per port
    • Priority-based QoS handling as specified in IEEE 802.1Q
    • Per-port priority remapping and 8 configurable egress queues per port
    • Optional double-tagging support
    • Hardware support for IEEE 802.1AS timestamping and IEEE 802.1Qav AVB traffic shaping
    • 16 credit-based shapers available according to IEEE 802.1Qav; shapers can be freely allocated to any priority queue on a per port basis
    • Support for SR Class A, Class B, and Class C traffic
    • IEEE 1588v2 one-step sync forwarding in hardware
    • Frame mirroring and retagging for enhanced diagnostics
    • Statistics for dropped frames and buffer load
    • RFC2819 support for counters

    Ethernet security
    • IEEE 802.1X hardware support for EAP filtering, reachability and disabling address learning
    • Extensive filtering rules for frame forwarding, retagging, tunneling and double-tagging
    • Address learning space can be configured for static and learned addresses
    • Enhanced support for address learning restrictions for security
    • Ingress rate-limiting on a per-port basis for Unicast/Multicast and Broadcast traffic
    • Broadcast storm protection

    TT and TSN features (SJA1105/Q/S only)
    • IEEE 802.1Qbv time-aware traffic
    • IEEE 802.1Qci per-stream policing (pre-standard)
    • Support for ring-based redundancy (for time-triggered traffic only)
    • 1024 deterministic Ethernet flows with per-flow based:
    – Time-triggered traffic transmission
    – Ingress policing and reception window check
    – Statistics

    Interface features
    • MII/RMII for interfacing with 10/100 Mbit/s PHYs/host processor (Fast Ethernet)
    • RGMII for interfacing with 10/100/1000 Mbit/s PHYs/host processor (with external delay components)
    • RGMII-ID (with internal delay) for interfacing with 1000 Mbit/s PHYs/host processor
    • SGMII for interfacing with 10/100/1000 Mbit/s PHYs/host processor/cascading
    • MAC and PHY modes for interfacing (MII/RMII/RGMII/SGMII) directly with another switch or host processor
    • Programmable drive strength for MII/RMII/RGMII interfaces
    • SPI for host processor access

    Other features
    • 25 MHz system clock input from crystal oscillator or AC-coupled single-ended clock
    • 25 MHz reference clock output
    • Device reset input from host processor
    • Synchronization output for cascading devices
    • IEEE 1149.1/1149.6 compliant JTAG interface for TAP controller access and BSCAN


    Other Electronic Components In Stock

    Part Number

    Package

    SDINBDA6-256G-I1

    BGA

    SDINBDG4-64G-A

    BGA

    SDINBDG4-32G-A

    BGA

    SDINDDH4-128G

    BGA

    SDINDDH6-128G-XI

    BGA

    SDINDDH6-64G-XI

    BGA

    SDINBDV4-128G

    BGA

    SDINBDV4-256G

    BGA

    SDINBDG4-64G-ZA2

    BGA

    SDINBDA6-32G-XA1T

    BGA

    SDINBDA6-64G-ZA1T

    BGA

    SDINBDG4-64G-ZAT2

    BGA

    SDINDDH6-16G-XI

    BGA

    SDINDDH6-256G-XAT

    BGA

    SDINDDH6-64G-ZA

    BGA

    SDINBDV4-64G-P

    BGA

    SDINDDH6-16G-XA2

    BGA

    1SG065HH1F35I2LG

    1152-BBGA

    1ST040EH1F35I1VG

    1152-BBGA

    5AGTFD7H3F35I3G

    1152-BBGA

    5AGZME7K3F40C4G

    1517-BBGA

    5AGZME3H2F35I3LG

    1152-BBGA

    5AGZME5K3F40I4G

    1517-BBGA

    5AGZME5K2F40C3G

    1517-BBGA

    1SG085HN3F43E1VG

    1760-BBGA

    1ST040EH1F35I2LG

    1152-BBGA

    1SG110HN3F43I3VG

    1760-BBGA

    1SG110HN3F43E2VG

    1760-BBGA

    1SG110HN3F43E2VGS1

    1760-BBGA

    1SD110PJ3F43E3VG

    1760-BBGA
