XR-X100WP KEYENCE Autofocus Code Reader Wide-field type (1.4 megapixels) PoE models

KEYENCE XR-X100WP Autofocus Code Reader Wide-field type PoE models:

The KEYENCE XR-X100WP is a wide-field autofocus code reader designed for high-speed, high-precision barcode and 2D code scanning in industrial environments. It features a 1.4-megapixel CMOS image sensor, enabling reliable reading of micro-sized codes (minimum resolution: 0.060 mm for 2D codes, 0.082 mm for barcodes) at distances ranging from 50 mm to 1,000 mm.

This model supports PoE (IEEE 802.3af Class 3), allowing simultaneous power and data transmission over Ethernet, reducing cabling complexity. Its IP65/IP67-rated enclosure ensures dustproof and waterproof performance, making it suitable for harsh manufacturing, logistics, and warehouse settings.

Technical Specifications:

Power Supply & Consumption

PoE Class 3: IEEE 802.3af compliant.

Max Power: 13 W (peak), 3.3 W (average), 2.5 W (standby).

Environmental Resistance

Operating Temperature: 0°C to +45°C (32°F to 113°F).

Storage Temperature: -10°C to +50°C (14°F to 122°F).

Humidity: 35% to 85% RH (non-condensing).

Physical & Weight

Dimensions: Approx. 67 × 63 × 31 mm (2.64 × 2.48 × 1.22 inches).

Weight: 180 g (6.35 oz).

Reading Performance

Field of View: 189 × 142 mm (7.44 × 5.59 inches) at 300 mm distance.

Reading Distance: 50 mm to 1,000 mm (1.97" to 39.37").

Supported Codes: QR, DataMatrix, PDF417, CODE39, CODE128, EAN/UPC, ITF, and more.

I/O & Control

Photo MOS Relay Outputs: 3 outputs, max 50 mA per channel (100 mA total).

Residual Voltage: ≤1 V (ON), Leakage Current: ≤0.1 mA (OFF).

Packing & Delivery:

1)100% brand New and Original Factory Seal!

2)Warranty: 1 year

3)Package: Original packing with cartons.

4)Delivery time: Shipped in 3-7 days after payment

5) All the goods will be tested before shipment.
