    60m2/H Mimaki Flatbed Printer JFX500-2131 Large Format UV LED Printer

    Max Speed 60m2/h Powerful combination of Speed and Quality Mimaki JFX500-2131 Large Format UV LED Flatbed inkjet Printer
    Product Description

    Max Speed 60m2/h. Powerful combination of Speed and Quality.


    For amazing speed, the JFX500-2131 is equipped with Mimaki’s latest print head and UV LED technology.
    Mimaki’s exclusive head control technology delivers an amazing high print quality.
    This combination of "Speed" and "High quality" are essential for large format printers.
    Both of them indeed come true in the newly released JFX500-2131!

    The JFX500-2131 sets a milestone in design and performance from Mimaki, offering a newly developed print head, UV ink and advanced UV LED curing features.

    Specifications

    JFX500-2131
    HeadOn-demand Piezo head (6 printheads with 3 staggered configuration)
    Print resolution300dpi, 600dpi, 900dpi, 1,200dpi
    InkUV curable inkLUS-120 (C, M, Y, K, W, Cl)
    LUS-150 (C, M, Y, K, W)
    LUS-200 (C, M, Y, K, W)
    LH-100 (C, M, Y, K, W, Cl)
    PR-100, PR-200 (Primer)
    Supply systemSupplied by 2L Ink Station
    Ink circulation (*1)White ink circulation by MCT (Mimaki Circulation Technology)
    Ink degassing moduleEquipped with MDM (Mimaki Degassing Module)
    Maximum print size (W X D)2,100 X 3,100 mm (82.7 X 122.0")
    MediaSize (W X D)2,100 X 3,100 mm (82.7 X 122.0")
    HeightMax. 50 mm (2.0")
    WeightLess than 50 kg (110.2 lbs.) / m2
    Media tableAir suction by vacuum
    Vacuum areaVertically divided into 4 zones
    Print accuracyAbsolute accuracy± 0.3 mm (0.01") or ± 0.3% from specified print distance
    Repeatability± 0.2 mm (0.01") or ± 0.1% from specified print distance
    UV unitEquipped with UV LED (Light Emitting Diodes)
    Lifetime (*2)About 5,000 hours
    InterfaceUSB2.0
    Applicable standardVCCI class A, CE Marking, CB Report, UL, RoHS Directive
    Power specificationsAC 200 – 240 V, 50/60 Hz
    Power consumptionLess than 2.4 kVA
    Operational environmentTemperature15 – 30 °C (59 – 86 °F)
    Humidity35 – 65 %Rh
    Temperature accuracy18 – 25 °C (64.4 – 77 °F)
    Temperature gradientLess than ± 10 °C/h (18 °F)
    DustEquivalent to normal office level
    Dimensions (W X D X H) (*3)4,100 X 4,462 X 1,490 mm (161.4 X 175.7 X 58.7")
    Weight (*3)1,353 kg (2,982.8 lbs.)
