    Precision Small Injection Molding Machine with Servo System

    Ask Lasest Price
    Brand Name : didaINT
    Model Number : EL-436
    Certification : ISO9001
    Price : 10000
    Payment Terms : D/P,T/T,Western Union
    Supply Ability : 100unit/month
    Delivery Time : 3-7days
    • Product Details
    • Company Profile

    Precision Small Injection Molding Machine with Servo System

    Precision Small Injection Molding Machine with Servo System

    This EL-436 series mini injection molding machine is ideal for producing small, high-precision plastic components, especially suited for food-related products such as custom utensils, containers, caps, and miniature parts. It serves industries requiring clean, efficient, and repeatable micro-molding solutions.

    Features

    • Servo System: Ensures fast, smooth, and energy-efficient operation.

    • Automatic Ejection & Forming: Reduces manual intervention and increases productivity.

    • Low Machine Height: Easy feeding, maintenance, and flexible installation.

    • Wide Material Compatibility: Works with PP, PC, ABS, PE, PA6, PS, PEI, PMMA, POM, TPU, TPE, and more.

    • Precision Control: Excellent repeatability for consistent output quality.

    Specifications Table



    Specification CategoryDetails20T25T40T60T
    Injection Unit




    Screw Diameter (mm)mm22222528
    Injection Pressure (kg/cm²)kg/cm²2170217019602170
    Injection Quantity (g/oz)g/oz40/1.440/1.464/2.280/2.8
    Screw Stroke (mm)mm110110110140
    Nozzle Stroke (mm)mm150150200200
    Clamp Unit




    Clamping Force (Tons)Tons20254060
    Platen Size (mm)mm380x290380x290430x430470x470
    Tie-Bars Spacing (mm)mm250x200250x200280x280310x310
    Min Mold Thickness (mm)mm100/40130/100120/160160/200
    Mold Opening Stroke (mm)mm215215215250
    Max Mold Opening Distance (mm)mm255/315315/345340/380410/450
    Power Unit




    Max Hydraulic Pressure (kg/cm²)kg/cm²140140140140
    Motor Power (KW)KW4447.5
    Total Power Consumption (KW)KW666.411.5
    Other




    Machine Weight (kg)kg1000100015002000
    Machine Dimensions (mm)mm
    2020x600x14002400x700x15002600x700x1500


    Factory presentation

    FAQ

    1. What materials can the XH-436 mini injection molding machine process?
      It supports a wide range of thermoplastics, including PP, PC, ABS, PE, PA6, PS, PEI, PMMA, POM, TPU, and TPE.

    2. Is this machine suitable for food-grade product manufacturing?
      Yes, the XH-436 series is designed to produce small, precision parts suitable for food-related applications, provided compatible food-grade materials are used.

    3. How energy-efficient is the servo system?
      The servo system offers super energy-saving performance, reducing power consumption while maintaining fast and stable operation.

    4. What is the maximum clamping force available?
      The XH-436 series offers models with clamping forces from 20T to 60T to suit different production needs.

    5. Does the machine support automatic product ejection?
      Yes, it features automatic product dropping and forming, minimizing manual handling and improving efficiency.
