Logic ICs 1-Bit Bidirectional Voltage-LevelTranslator With Auto Direction Sensing

    Buy cheap Logic ICs 1-Bit Bidirectional Voltage-LevelTranslator With Auto Direction Sensing from wholesalers

    Buy cheap Logic ICs 1-Bit Bidirectional Voltage-LevelTranslator With Auto Direction Sensing from wholesalers
    • Buy cheap Logic ICs 1-Bit Bidirectional Voltage-LevelTranslator With Auto Direction Sensing from wholesalers
    • Buy cheap Logic ICs 1-Bit Bidirectional Voltage-LevelTranslator With Auto Direction Sensing from wholesalers
    • Buy cheap Logic ICs 1-Bit Bidirectional Voltage-LevelTranslator With Auto Direction Sensing from wholesalers

    Logic ICs 1-Bit Bidirectional Voltage-LevelTranslator With Auto Direction Sensing

    Ask Lasest Price
    Brand Name : UCHI
    Model Number : SGM4554
    Certification : Completed
    Price : Negotiable
    Payment Terms : T/T,Western Union
    Supply Ability : 5000pcs
    Delivery Time : 3weeks
    • Product Details
    • Company Profile

    Logic ICs 1-Bit Bidirectional Voltage-LevelTranslator With Auto Direction Sensing

    Logic ICs 1-Bit Bidirectional Voltage-LevelTranslator With Auto Direction Sensing
    The SGM4554 is a 1-bit, non-inverting, bidirectionalvoltage-level translator which features two independentconfigurable power-supply lines. The A and B portstrack the VCCA supply and VCCB supply respectively. Thesupply voltage range is 1.2V to 5.0V for A port and1.65V to 5.5V for B port. The device provides abidirectional translation function among the differentvoltage nodes (including 1.2V, 1.5V, 1.8V, 2.5V, 3.3Vand 5V).The SGM4554 has an output enable (OE) function,which controls the outputs states. When OE goes low,all outputs enter into the high-impedance state. The OEshould be connected to GND via a pull-down resistor,and the minimum resistor value is depended on thecurrent source capability of the driver.The SGM4554 is available in Green UTDFN-1.45×1-6Land SC70-6 packages. It operates over an ambienttemperature range of -40℃ to +85℃.
    Key Features

    ● Power Supply Voltage Range (VCCA ≤ VCCB)
     A Port: 1.2V to 5.0V
     B Port: 1.65V to 5.5V
    ● Support VCCA or VCCB Isolation
     When VCCA or VCCB is Low, Device EntersPower-Down Mode
    ● OE Input Circuit Referenced to VCCA
    ● Support Partial-Power-Down Function
    ● Support Push-Pull Output
    ● Low Power Consumption
    ● -40℃ to +85℃ Operating Temperature Range
    ● Available in Green UTDFN-1.45×1-6L and SC70-6Packages

    Applications
    Universal Asynchronous Receiver/Transmitter
    General Purpose I/O (GPIO)

    Typical Application

    Pin Configurations

    Pin Description
    Product Selection Guid
    Translators
    per
    Package
    Part Number
    Data
    Rate
    (Mbps)
    Vcc
    (V)
    VL
    Range
    (V)
    VCCA
    Range
    (V)
    VCCB
    Range
    (V)
    Bidirectional
    VCC
    Shutdown
    I/O State
    Shutdown ICC
    Max
    (μA)
    Logic
    Output
    Package
    Features
    1SGM4554100

    1.2~5.01.65~5.5YesHi-Z10Push-Pull
    SC70-6,UTDFN-1.45×1-6L
    GPIO Level Shifter
    1SGM4555
    2.7~5.51.4~5.5

    YesLoW

    TQFN-2×2-12L,TQFN-3×3-16L
    Card Interface
    2SGM4556100

    1.2~5.01.65~5.5YesHi-Z10Push-Pul
    SOT-23-8,XTDFN-1.4×1-8L
    GPIO Level Shifter
    2SGM4558
    2.7~5.51.4~5.5

    YesLoW2
    XTDFN-1.35×1-8L
    SIM/Smart Card Interface
    1SGM4560
    3.3~5.51.6~5.5

    YesLoW8
    TSSOP-14
    CA Card Interface
    1SGM4561
    5.0~5.51.6~5.5

    YesLoW

    MSOP-10
    HDMI Interface
    4SGM4563100

    1.2~5.51.65~5.5NoHi-Z5Push-Pul
    SOIC-14,UTQFN-1.8×1.8-12L
    SPI Bus or UART Interface
    4SGM4564100

    1.2~5.51.65~5.5YesHi-Z12/9Push-Pul
    SOIC-14,UTQFN-1.8×1.8-12L,TQFN-2×2-12L
    GPIO Level Shifter
    1SGM4565


    1.08~1.981.62~3.6YesLoW
    Open-Drain
    UTQFN-1.8×1.4-10L,WLCSP-1.06×1.06-9B
    SIM Card Interface Level Translator
    6SGM4566100

    1.2~5.51.65~5.5YesHi-Z12/9Push-Pul
    TSSOP-16,TQFN-2.6×1.8-16L
    GPIO Level Shifter
    8SGM4568100

    1.2~5.51.65~5.5YesHi-Z12/9Push-Pul
    TSSOP-20,TQFN-3×3-20L
    GPIO Level Shifter
    4SGM4570Q24/2

    1.65~3.62.3~5.5YesHi-Z
    Open-Drain/Push-Pull
    TSSOP-14
    Automotive, Open-Drain, Dual-Supply Translating Transceiver
    4SGM457324/2

    1.65~3.62.3~5.5YesHi-Z
    Open-Drain/Push-Pull
    TSSOP-14,TQFN-3.5×3.5-14AL
    Open-Drain, Dual-Supply Translating Transceiver
    4SGM457424/2

    1.65~5.52.3~5.5YesHi-Z
    Open-Drain/Push-Pull
    SOIC-14,UTQFN-1.8×1.8-12L,TQFN-2×2-12,TQFN-3.5×3.5-14AL
    GPIO Level Shifter
    6SGM457624/2

    1.65~5.52.3~5.5YesHi-Z
    Open-Drain/Push-Pull
    TQFN-2.6×1.8-16L
    GPIO Level Shifter
    8SGM457824/2

    1.65~5.52.3~5.5YesHi-Z
    Open-Drain/Push-Pull
    TSSOP-20,TQFN-3×3-20L
    GPIO Level Shifter
    15SGM4590
    2.5~5.5


    No


    TQFN-4×4-32L
    GOA Panel 15-Channel Level Shifter
    4SGM4T245


    1.2~5.01.2~5.0YesHi-Z
    Push-Pul
    TSSOP-16,TQFN-2.6×1.8-16L
    4-Bit Dual-Supply Translating Transceiver
    8SGM8T245


    1.2~5.01.2~5.0YesHi-Z
    Push-Pul
    TSSOP-24,TQFN-5.5×3.5-24L
    8-Bit Dual-Supply Translating Transceiver
    8SGM8T245S


    1.2~5.51.2~5.5YesHi-Z
    Push-Pul
    TSSOP-24,TQFN-5.5×3.5-24L
    8-Bit Dual-Supply Bus Transceiver


    Integrated circuits (ICs) serve as the foundation of modern electronics, offering small size, low power consumption, strong performance and high reliability. They are widely used in consumer electronics, industrial applications, communications, automotive electronics, medical equipment, and aerospace/defense systems.
    Electronic components and circuit board applications
    Uchi Electronics provides high-performance analog and mixed-signal processing solutions for industrial automation, new energy, automotive, communications, computing, consumer electronics and medical equipment applications.

    This solution demonstrates the integrated circuit application of the digital output module . For assistance selecting the right product, please contact our technical support team.
