Product Description:
Introducing our high-quality Optical Cylinder Lens, a versatile
product designed to meet your specific optical needs. This
precision-engineered lens is ideal for applications requiring
precise beam shaping and manipulation, making it a valuable tool
for various industries and research fields.
The Optical Cylinder Lens is designed to operate at a design
wavelength of 632.8nm, ensuring optimal performance and accuracy in
your optical systems. With a coating wavelength range of 400-700nm,
this lens offers versatility and compatibility with a wide range of
light sources and applications.
One of the key features of this lens is its exceptional surface
flatness of λ/4, ensuring minimal distortion and aberration for
precise imaging and beam control. Whether you are conducting
research, performing measurements, or implementing optical systems,
this lens delivers consistent and reliable results.
Designed for one-dimensional beam shaping, the Optical Cylinder
Lens allows you to sculpt and direct light with precision and
efficiency. Whether you need to focus, collimate, or shape a beam,
this lens provides the optical control you need to achieve your
desired results.
With a size of 25.4mm, this compact and lightweight lens is easy to
integrate into your optical setups and systems. Its durable
construction and high-quality materials make it suitable for a wide
range of applications, from industrial processes to scientific
research.
Whether you are working on laser systems, imaging applications, or
optical instrumentation, the Optical Cylinder Lens offers the
performance and reliability you need to achieve your goals. Its
aspherical optical design and cylindrical glass construction ensure
high precision and consistency in your optical setups.
Whether you are designing a dome camera lens, optimizing a laser
system, or conducting research in optics, the Optical Cylinder Lens
is a valuable tool that offers exceptional performance and
versatility. Its precise beam shaping capabilities and reliable
performance make it an essential component for your optical
projects.
Features:
- Product Name: Optical Cylinder Lens
- Surface Flatness: λ/4
- Coating Wavelength Range: 400-700nm
- Polishing: N<3(0.5)@632.8nm
- Raw Material: Optical Glass
- Working Wavelength: UV, VIS To IR
Technical Parameters:
| Substrate | Optical Glass |
| Raw Material | Optical Glass |
| Shape | Cylindrical |
| Working Wavelength | UV, VIS To IR |
| Size | 25.4mm |
| Coating Wavelength Range | 400-700nm |
| Surface Flatness | λ/4 |
| Polishing | N<3(0.5)@632.8nm |
| Feature | One Dimensional Beam Shaping |
| Clear Aperture | >90% |
Applications:
STAR OPTIC's CYX Optical Cylinder Lens is a versatile product
suitable for a wide range of applications in various industries.
With its high quality and reliability, this lens is perfect for use
in industrial settings where precision and clarity are essential.
The optical cylinder lens is ideal for use in industrial imaging
systems, such as machine vision cameras, where it can enhance image
quality and provide accurate measurements. Its clear aperture of
over 90% ensures maximum light transmission, making it suitable for
use in low-light conditions.
Whether you need to focus light, shape laser beams, or correct
aberrations, the CYX lens offers excellent performance across a
wide working wavelength range, from UV to IR. This makes it a
versatile choice for applications requiring different wavelengths
of light, such as infrared imaging.
Manufactured in Wuhan, China, the lens is produced using
high-quality optical glass, ensuring durability and reliability. It
meets stringent quality standards, with RoHS and ISO9001
certifications, providing assurance of its performance and safety.
The CYX lens is available in various dimensions, including
10x20~20x20 and custom sizes, allowing for flexibility in design
and application. Its cylindrical shape makes it easy to integrate
into optical systems, providing precise control over light
propagation.
When ordering the CYX lens, customers can benefit from STAR OPTIC's
flexible terms, including a minimum order quantity of 5pcs,
negotiable pricing, and payment options such as T/T, Western Union,
and Paypal. The lens is supplied in safe and dust-free packaging,
ensuring it arrives in perfect condition.
With a supply ability of 50000pcs per month, STAR OPTIC can meet
the needs of both small and large-scale projects. Whether you are
designing industrial lenses, infrared systems, or other optical
applications, the CYX Optical Cylinder Lens is a reliable and
high-performance choice.
