TRG50A-110 50m³/h Screw Pump : special transfer pump for drilling and solid control
Screw pump is an ideal pump for feeding to decanter centrifuge. The
main parts are screw shaft(rotor) and screw shaft bushing(stator).It can drive by coupler, or adjust the speed
by using variable speed motor, triangle V-belt and gear box etc.
Advantage
✅Strong self-priming ability: It has good self-priming performance and can pump fluid without a
priming pump.
✅Smooth conveying with minimal pulsation: Uniform and continuous flow without turbulence and shear pulsation,
ideal for conveying shear-sensitive media.
✅Complex media: Efficient delivery of high-viscosity media, solid particle
slurries, and gas-liquid-solid three-phase mixing media.
✅The flow rate is strictly proportional to the rotational speed: the flow can be controlled directly and precisely by adjusting the
rotational speed.
✅Stable pressure output: It can output extremely high pressure at lower speeds and the
pressure is stable.
Technical Specifications
Model | TRG50A-110 |
Flow Rate | 50m³/h |
Pressure | 0.3Mpa |
Power | 11kw |
Inlet(inch) | 5 |
Outlet(inch) | 5 |
EX Standard | ExdllBt4/IECEX/A-TEX |
Weight | 608kg |
Dimension | 3790×400×782mm |
Application
• Oil & Gas Drilling: Solid control systems for onshore and offshore rigs.
• Coalbed methane drilling: The exploitation of unconventional oil and gas resources such as
shale gas.
• Horizontal Directional Crossing (HDD): Mud circulation system in trenchless engineering projects.
• Mining, metallurgy, dredging: conveying abrasive media such as tailings, concentrate, slurry,
etc.
• Municipal environmental protection: river dredging, sewage treatment plant sludge transportation.
Certifications
· API & ISO 9001 Certified: Meets stringent international quality and
safety standards.
