    Low Energy Consumption Automatic Paper Egg Tray Packaging Machine and Pulp Molding Machine with Dryer Metallic Dryer Simple Design

    Ask Lasest Price
    Brand Name : WANYOU
    Model Number : WY-1
    Price : USD8800/SET
    Payment Terms : T/T,Western Union,MoneyGram
    Supply Ability : 1SET PER MONTH
    Delivery Time : 40 working days
    • Product Details
    • Company Profile

    Low Energy Consumption Automatic Paper Egg Tray Packaging Machine and Pulp Molding Machine with Dryer Metallic Dryer Simple Design

    Low Energy Consumption Automatic Paper Egg Tray Packaging Machine and Pulp Molding Machine with Dryer Metallic Dryer Simple Design


    Product Information

    There are 2 models for customer to choose, semi automatic one without dryer, fully automatic one with dryer.

    Main sections of the paper egg tray machine:

    1. pulping system: including the hydrapulper, pump, water tank, pulp tank, mixer, etc..to make the wastepaper into paper pulp.

    2. forming system: including the molding machine, molds, vacuum pumps, air compressor and electrical controller to make the pulp into wet trays.


    3 molds paper egg tray machine forming part 1000pcs/h capacity



    Simple structure egg tray machine with cheaper investment

    1*2 molds paper egg tray machine 700pcs/h capacity forming part


    3. Dryer system for egg tray machine( Optional for customer)

    Metalic dryer model (4 layers, 6 layers, customized as per customer's needs) for egg tray machine

    Heat source (fuel) for egg tray machine dryer: natural gas, diesel, liquefied petroleum gas and other combustion liquids and gases.The transmission mode adopts industrial transmission chain to drive the net plate transmission, which runs in the drying line.

    Various capacity egg tray machine / egg tray production line we can make

    Egg tray mould quantity

    1pcs

    2pcs

    3pcs

    4pcs

    Raw material

    Waste paper

    Waste paper

    Waste paper

    Waste paper

    Output for egg tray

    350pcs/hour

    700pcs/hour

    1000pcs/hour

    1300pcs/hour

    Net weight per piece (gram)

    70g-75g

    70g-75g

    70g-75g

    70g-75g

    The volume of waste paper consumed

    0.025ton / hour

    0.06ton / hour

    0.1ton / hour

    0.13ton / hour

    The volume of water consumed

    0.05ton / hour

    0.15ton / hour

    0.2ton / hour

    Operators number

    2-3workers

    3-4workers

    4-6workers

    4-6workers

    Area of workshop

    More than 200M²

    More than 240M²

    More than 240M²

    More than 240M²

    Capacity of power

    25KW

    40KW

    50KW

    60KW

    1000pcs/h capacity 3 molds egg tray machine technical data

    Egg Tray Mold Quantity

    3pcs

    Raw material

    Waste paper

    Egg tray Capacity

    1000pcs/hour

    Net weight per piece (gram)

    70g-75g

    Waste paper consumption

    75kg / hour

    Water Consumption

    0.15ton / hour

    Natural Gas Consumption of Dryer

    35cbm/h

    Worker requirement

    4-6workers

    Machine Length

    7m-25m

    Machine weight

    8-20tons

    Power Requirement

    Without dryer

    40KW

    With dryer

    60KW

    Area of workshop

    Without dryer

    More than 120 M²

    With dryer, dryer-16m

    More than300M²

    Container Requirement

    Without dryer

    40ft*1

    With dryer

    40ft*3

    Remarks:

    1. The egg tray Capacity calculated base on 30-packed egg tray(size 300x300mm, weight 70g~75g).

    2. Workshop size is for reference only and could be adjusted according to actual size of client’s plant.

    End product of paper egg tray machine


    Payment Terms

    Delivery Time: 40 working days after getting payment

    Payment Terms: 40% T/T prepayment in advance.

    60% before delivery by T/T.

    Warranty time

    1year after the Egg tray machine received.

    Terms of delivery

    EXW Jinan, China

    Time of payment

    When the deposit is paid, the machine will begin to be produced. And the balance should be paid by the consignee (the buyer) before the delivery.
