C09：Heavy Duty Steel Pallet Racking System Warehouse Steel Storage Racks Industrial Adjustable Shelving Large Capacity

Heavy Duty Pallet Rack

——

Single Deep

Heavy duty pallet rack is the main components of every warehouse system. Single selective rack is pallet rack in which every pallet is accessible from an aisle. This is the most common of all rack designs and assures that any pallet can be accessed at any time.
Commonly known as adjustable pallet racking, this is perhaps the most popular and economical form of pallet racking because it provides 100% selective storage up to 12.8 Meters in height, fully utilizing valuable air space.Heavy duty pallet rack can be used as a stand-alone for pallet storage or as part of complex engineered systems for carton flow or pallet flow modules.

Heavy duty pallet rack usually consist of upright frame, beam, pallet support bar and other standards components. H-bracing and d-bracing connect with upright by nylon self-lock boltscan effectively prevent racking from losing balance cause by the release of the bolts; drum-shaped holes are punched on the upright, so beam can be adjusted. Standard pallet racking is by far the most versatile of any racking as it is available with many configurations, a wide range of accessories and requires no specialized handling equipment. Pallet racking is easily utilized with just standard fork- and hand-trucks. Pallet racking is an ideal starting point for all your warehouse and storage needs.

Heavy Duty Pallet Rack · Warehouse Storage Rack · Made In China

Features & Advantages

——

1.It is simple structure, safe and reliable and can be adjusted and combined at will, and the order of items in and out of the warehouse is not restricted. It is widely used in storage modes with pallet storage and forklift access.
2.The column group is connected by bolts with columns, cross braces and diagonal braces. The column group and C-shaped welded beam are plugged into the shelf frame, fixed with safety pins, and the structure is simple and reliable. Each layer can be freely adjusted up and down with a step of 50mm.
3.The beam shelf has the characteristics of large moment of inertia, strong layer load capacity and strong impact resistance. The maximum layer load of each layer can reach 5000kg/layer under relative design.
4.The plasticity is very large. Mold shelves, loft shelves, stereoscopic warehouse shelves, etc. can be built on the basis of pallet shelves. Special oil drum shelves can also be made.
5.The beam racks can effectively increase the storage height of the warehouse and improve the space utilization rate of the warehouse. Suitable for storage of all types of goods.
6.The appearance is safe, and column foot guards and anti-collision bars can be added to prevent forklift collisions. In order to make the layer loading safer, ancillary facilities such as beam shelves, layer boards, mesh cross beams, etc. can also be placed on the beams.
7.Low cost, easy installation and operation, easy to find cargo positions, suitable for any handling tools.
8.The beam shelves can also be equipped with layer boards, which can be steel plates, melamine plates or grid nets. So that pallets of different sizes can be used.
9.Simplicity: The simplest industrial production concept that is easy to understand is used. In addition to the load description, the equipment does not need to consider too much precise data and structural rules. Production line operators can design and make them according to their own workstation conditions.
10.Improve the working environment: In addition to reducing the time and round-trip movement required for picking up and placing parts and tools, the workstation system can also protect the work and workers.

Heavy Duty Pallet Rack · Warehouse Storage Rack · Made In China

Pallet Storage Solutions

—

Heavy Duty Pallet Rack · Warehouse Storage Rack · Made In China

Structural Principles

——

The safety bolt is used to fix the column and beam. Which is moresecure and stable.

Columns are fixed with screws,Use screws to fix horizontal anddiagonal supports.

Super strong welded beam,the beam adopts girders toincrease the load-bearingperformance of the beam.

The foot piece USES the oversize , the ultrathick welding ground piece , increases itsfirmness fixes with the expansion screw.

Start Shelf and Add-On Shelf analysis

——

The crossbeam adopts the holding weldingbeam, and both ends are welded with hang-ers, also known as column clamps, to con.Nect the columns; the height of the beam can be freely adjusted in multiple of 75mm.Common hole type is diamond hole.

Different Choices Of Panel For Holding Goods

——

Back Mesh Side Mesh

——

Upright

——

Section : 80×60 / 90 × 70 / 100×70 / 120×95

Features : Made with mould,Good loading capacity,Easy assembly

Beam

——

Section : 50×80 / 50 ×100 / 50×120 / 50×140 / 50×160 ////// 40×80 / 40 ×100 / 40 ×120 / 40 ×140 / 40×60

Distributed Loading Chart

——

Heavy Duty Pallet Rack · Warehouse Storage Rack · Made In China

Racking Protection

——

Protect warehouse racking from vehicle damage with purpose-engineered racking solutions.

Prevent damage to rack legs
Rackguards prevent impact and scrape damage to the front and sides of rack legs during loading and unloading.
Protect vulnerable rack ends
Turning points at the ends of racking aisles can be impact hotspots. rack end barriers and bollards can soften sharp corners and deflect frequent glancing blows from turningforklift trucks .

No Floor Damage
Flexible industrial polymer and patented engineering absorbs and disperses impactforces to protect fixings and prevent floor damage.
Save On Repairs
Engineered with built-in memory to flex and fully recover from impacts, unique polymer design protects against costly barrier and vehicle damage.

Save On Maintenance
Self-coloured non-corrosive and uv protected , advanced polymer barriers stayvisible , do not rust and never need painting saving you time and money.
Flex And Recover
Advanced polymer gives pedestrian barriers extreme strength and aunique built-in memory to flex and recoverfrom multiple impacts.

Heavy Duty Pallet Rack · Warehouse Storage Rack · Made In China

CASE

—

Heavy Duty Pallet Rack · Warehouse Storage Rack · Made In China

Heavy Duty Pallet Rack · Warehouse Storage Rack · Made In China

Heavy Duty Pallet Rack · Warehouse Storage Rack · Made In China

Heavy Duty Pallet Rack · Warehouse Storage Rack · Made In China

Heavy Duty Pallet Rack · Warehouse Storage Rack · Made In China

Heavy Duty Pallet Rack · Warehouse Storage Rack · Made In China

Heavy Duty Pallet Rack · Warehouse Storage Rack · Made In China

Heavy Duty Pallet Rack · Warehouse Storage Rack · Made In China

ABOUT US

—

Anhui Huayide Intelligent Storage Equipment Co., Ltd. (the promitive name Anhui Huarunde logictics equipment Co., Ltd, Establised in 2009) is located in Hefei Binhu Science City, Anhui Province. It focuses on the development and promotion of intelligent logistics equipment, integrating scientific research and development, manufacturing, system integration, marketing and engineering services, committed to providing world-class internationally competitive intelligent logistics equipment, products and solutions, covered automation and intelligent manufacturing. Our products are widely used in power, automotive, chemical, logistics, public utilities, manufacturing and other industries.

We have strong technical, relying on the deep cooperation between Anhui Polytechnic University, research institute of University of Science and Technology of China and well-known enterprises. In the process of product research and development, it has absorbed a large number of advanced technologies and concepts,possesses comprehensive technical research and development capabilities of intelligent logistics equipment. We have extremely profound accomplishments project planning, intelligent manufacturing, intelligent electrical control, computer software development, and engineering project management .

We have:
professional shelf raw material strength testing machine , column load testing machines and beam load testing machines.

We have:
a complete set of shelf surface coating quality testing equipment: cross-cut testing machine, cupping testing machine, electronic magnetic thickness gauge, gloss measuring instrument, salt spray testing machine, etc.

We have passed :
IS09001 quality system certification, IS014001 environmental system certification, ISO18001 occupational health system certification. Tested by the European research institute, we passed various indicators such as safety and environmental protection, obtained CE certification, and obtained a sales pass to enter the European market.

Company Details ( Click to enter )

Production Line ( Click to enter )

Contact Us ( Click to enter )

Heavy Duty Pallet Rack · Warehouse Storage Rack · Made In China

FAQ

—

Q. What we do ?
Pallet Type Automated Storage and Retrieval System (Unitload AS/RS)
Box/ Container/ Crate/ Case Type Automated Storage and Retrieval System (Miniload AS/RS)
Shuttle Storage & Sequencing system
Rack-supported building type AS/RS
Semi-automated Radio Shuttle System
Electrical Mobile Racking System
Floor conveying & sortation system
Automatic Truck/Trailer Loading System
In HUAYIDE, you'll get turnkey solutions for engineering & consulting , design & manufacturing, implementation & training, commissioning & after-sale service. With the best throughput capacity to really in-house all your warehousing requirements, grow your business in a cost effective way.
Q. Why choose us?
Complete mastery of the process
Self-developed, engineered, produced and installed;
Very competitive pricing
Manufacturing in Asia save you up to 50%!
Integrated by us save you up to 25% more!
Successful cases backup
Projects in various industries ready for you to visit;
We upgrade on existing successful experience;
High-efficient
Instant communication are available 24/7/365;
Solutions for RFQ shall be obtainable within 36 hours;
Professional team work
We care and carry out your every single requirement;
We trained our engineers to speak English;
Reliable & Flexible
We study your market local regulations to comply with;
Credible backup documents for your evaluation;
Q. How we work?
Step 1 Define:HUAYIDE Solutions' engineers work with project stakeholders to determine project objectives
Step 2 Measure:Information is collected to help our engineers better understand your business.
Step 3 Analyze:Analyze data from your operating systems and create models that predict future states
Step 4 Design:Analyze data from your operating systems and create models that predict future states.
Step 5 Validate:System costs are estimated and a complete analysis is done to determine feasibility of each alternative.
Step 6 Client Presentation:Client is given final presentation of costs and best solution
