    AC/DC Coupling Industrial Commercial ESS with Fire Safety Certification 800kW Output

    Ask Lasest Price
    Brand Name : 1stess
    Model Number : EnerCube
    Certification : 1
    Price : negotiable
    Payment Terms : L/C,T/T
    Supply Ability : 10 containers per month
    Delivery Time : 60-90 days
    • Product Details
    • Company Profile

    AC/DC Coupling Industrial Commercial ESS with Fire Safety Certification 800kW Output

    Product Features:
    • Modular design
    • All-in-One design
    • Supports AC and Dc coupling
    • Standard 20HQ container
    • Classification society certification
    • 7*24 hours monitoring
    • Online assisted O&M
    Product Parameters:
    TypeP400C860P500C1075P600C1290P700C1505P800C1720
    DC side parameters
    Cell type &capacityLiFePO₄-280Ah
    Battery module type1P20S
    System configuration4*1P240S5*1P240S6*1P240S7*1P240S8*1P240S
    Capacity(BOL)860kWh1075kWh1290kWh1505kWh1720kWh
    AC side parameters
    Grid type3P4W+PE
    Rated output power400kW500kW600kW700kW800kW
    Rated voltageAC400V
    Rated frequency50/60(±5)Hz
    Maximum output current577A722A866A1010A1155A
    Harmonics<3%(@rated power)
    Overload capacity110%,10mins;120%,60s
    General parameters
    Isolation transformerNo
    Protection levelOutdoor installation (Battery cabinet:IP55,Electrical room:IP34)
    Container anti-corrosion gradeC3
    Operation temperature*-20℃~50℃
    Relative humidity0~95%(non-condensing)
    Permissible altitude**<2000m
    Cooling methodBattery cabinet:HVAC,Electrical room:forced air cooling
    Fire fighting systemFAS &FM200/Novec1230
    Noise emission≤75dB
    Dimension (W*D*H)20HQ container (6058mm*2438mm*2896mm)
    Maximum weight24500kg
    Communication interfaceEthernet
    Communication protocolModbus TCP/IP
    Warranty5 years (can be extended to 10 years)Warranty
    CertificationSystem:UN3536,LVD,EMC,RoHS Cell:IEC62619,UL1973,UL9540A PACK:UN38.3
    PCS:G99,EN50549,AS4777.2,VDE4105

    Core Advantages & Selling Points
    ✅ Simplified Deployment & Operations
    • Pre-integrated Plug-and-Play Design: Factory-assembled within standardized shipping containers, reducing on-site installation time by up to 70%.
    • Space-Efficient Transport: Optimized dimensions (20HQ container) enable global shipping and easy hoisting/lifting.
    • Modular Scalability: Expand capacity seamlessly from 860kWh to 1720kWh to match evolving energy needs.
    ⚡ High-Performance Energy Management
    • Dual AC/DC Coupling: Integrates effortlessly with solar arrays, wind turbines, diesel generators, or grid connections.
    • Industrial-Grade Output: Delivers 400kW–800kW rated power with low harmonic distortion (<3%) and overload resilience (110% for 10 mins).
    • Efficient Bidirectional Flow: Optimizes charging/discharging cycles for maximum energy utilization.
