Industrial L2+ 8-Port 10/100/1000T 802.3at PoE + 4-Port 1G SFP +
2-Port 10G SFP+ Managed Ethernet Switch
Product Overview:
The ETH-IMC2408MP Series is an advanced Industrial L2+ Managed
8+4+2 Port Multi-Gigabit PoE+ Ethernet Switch engineered for
high-performance networking in demanding environments. This robust
switch features 8× 10/100/1000BASE-T RJ45 ports with IEEE 802.3at
PoE+ support, 4× 1000BASE-X SFP fiber slots, and 2× 10G SFP+ ports,
providing exceptional connectivity flexibility for copper, gigabit
fiber, and multi-gigabit fiber networks.
The copper interfaces deliver up to 30W per port with
auto-negotiation, full/half-duplex operation, and auto MDI/MDI-X,
enabling seamless integration and power supply for IP cameras,
wireless access points, and various powered devices. The fiber
optic interfaces accommodate both single-mode and multi-mode
SFP/SFP+ modules (1 or 2 core), while the 10G SFP+ ports enable
high-speed backbone links for bandwidth-intensive applications.
Engineered with comprehensive Layer 2+ management capabilities,
this switch offers advanced features including VLAN, QoS, network
security protocols, and traffic prioritization. Built with a
hardened industrial design, it operates reliably in extended
temperature conditions and provides robust protection against
electromagnetic interference and mechanical stress. Ideal for data
centers, industrial automation, telecommunications, and other
mission-critical applications, the ETH-IMC2408MP ensures optimal
performance where high-speed data transmission, PoE power delivery,
and environmental durability are essential requirements.
Product Features:
✅ Hybrid Multi-Gigabit Connectivity: Features 8× 10/100/1000BASE-T RJ45 ports with IEEE 802.3at PoE+
support, 4× 1000BASE-X SFP slots, and 2× 10G SFP+ ports for
flexible integration of copper and multi-speed fiber networks.
✅ Advanced PoE+ Management: Delivers IEEE 802.3af/at compliant power with up to 30W per port,
supporting one-key PoE reset and extended 250m PoE transmission for
remote devices.
✅ Intelligent Auto-Negotiation Ethernet: All RJ45 ports support auto-MDI/MDIX, auto-negotiation, and
full/half-duplex operation for plug-and-play deployment.
✅ One-Key Network Configuration: DIP switch enables simplified one-key VLAN setup and one-key ring
network management for rapid deployment and maintenance.
✅ Modern Management Interface: Supports USB-C connectivity for easy configuration and
monitoring, eliminating the need for traditional RS232 serial port
access.
✅ Jumbo Frame Support: Enables 9K bytes jumbo frames for optimized data transmission
efficiency in high-bandwidth applications.
✅ Energy Efficiency Compliance: Meets IEEE 802.3az EEE standards, reducing power consumption
during low network activity periods.
✅ Rugged Industrial Protection: IP40-rated aluminum housing provides superior resistance against
dust, EMI, and mechanical stress.
✅ Flexible Installation Options: Supports DIN-rail mounting for secure deployment in control
cabinets and industrial settings.
Application Scenarios
Data Center Edge Connectivity: Provides multi-gigabit connectivity for server aggregation,
storage networks, and cloud access with 10G SFP+ uplinks, jumbo
frame support, and advanced traffic management.
High-Density Surveillance Networks: Supports multiple high-resolution IP cameras, PTZ systems, and
NVRs with IEEE 802.3at PoE+ power and fiber uplinks for enterprise
security systems.
Industrial Automation Backbones: Enables real-time control for PLCs, HMIs, and industrial IoT
devices with one-key VLAN and ring management for critical
manufacturing operations.
Telecommunications Infrastructure: Ideal for 5G fronthaul/backhaul connections and fiber aggregation
points with hybrid copper-fiber connectivity and carrier-grade
reliability.
Intelligent Transportation Systems (ITS): Deploys in traffic management centers and roadside cabinets with
extended 250m PoE support and wide-temperature operation.
Enterprise Network Core: Serves as distribution switch for campus networks, data-intensive
applications, and VoIP systems with L2+ management features.
Broadcast and Media Networks: Facilitates high-speed video transmission and media streaming
with 10G capability and jumbo frame support.
Smart City Infrastructure: Powers and connects urban communication systems, environmental
sensors, and public safety devices with robust industrial
protection.
Technical Indexes
| Standards: | IEEE802.3 10BASE-T |
| IEEE802.3u 100BASE-TX/FX |
| IEEE802.3ab 1000BASE-T |
| IEEE802.3z 1000BASE-X |
| IEEE802.3ae 10GBase-R |
| IEEE802.3p QoS |
| IEEE802.1d Spanning Tree |
| Forward & Filtering Rate: | 14,880pps (10Mbps) |
| 148,800pps (100Mbps) |
| 1,488,000pps (1000Mbps) |
| 1,488,000,000pps (10000Mbps) |
| Packet Buffer Memory: | 12M bits |
| Processing Type: | Store-and-Forward |
| Backplane bandwidth | 110Gbps |
| Max Packet Length: | 9K Bytes Jumbo Frame |
| Address Table Size: | 8K MAC Addresses |
| Interface |
| Connector: | 8 x RJ45 |
| Optical Port: | 4 x 1000Base-X SFP 2 x 10G Base-SR/LR SFP+ |
| USB-C: | 1 x USB-C (for Management) |
| PoE (Power over Ethernet) |
| Standard: | IEEE 802.3at Power over Ethernet Plus |
| IEEE 802.3af Power over Ethernet |
| Port: | RJ45 |
| Power Pin Assignment | 4/5(+), 7/8(-) |
| PoE Budget: | Up to 240-watt PoE budget |
| Environmental |
| Operating Temperature: | -40°C to 80°C (-40°F to 176°F) |
| Storage Temperature: | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity: | 5% to 95% non-condensing |
| MTBF | > 200,000 hrs |
| Electrical and Mechanical |
| Input Power: | 48~57VDC, Redundant Power (6-pin Terminal Block) |
| Power Consumption: | 8W Max.(PoE in Use<240W) |
| Protection: |
| Power Input Overload: | Automatic Resettable |
| Reverse Polarity: | Present |
| DIP Switch |
| 4-digit DIP switch function | DIP | Function | Settings |
| SW 1 | VLAN | ON - Enabled | OFF - Disabled |
| SW 2 | Ring Management | ON - Enabled | OFF - Disabled |
| SW 3 (to be upgraded) | 250m PoE Network | ON - Enabled | OFF - Disabled |
| SW 4 (to be upgraded) | PoE Reset | ON - Enabled | OFF - Disabled |
| LED Indicators: |
| PWR: | Power Status |
| Ethernet (Per Port): | Link/Activity |
| PoE (Optional) | PoE Status |
| Fiber: | Gigabit SFP Port: F9~F12 |
| 10G SFP+ Port: F13, F14 |
| Dimensions (WxDxH): | 149 x 114 x 50 mm |
| Weight: | 0.55Kg |
| Casing: | Aluminum Case |
| Mounting Options: | DIN-Rail mount |
| Regulatory Approvals |
| ISO9001, CE, RoHS, FCC |
Order Information
| Model | Description |
| ETH-IMC2408MP | Industrial L2+ 8-Port 10/100/1000T 802.3at PoE + 4-Port 1G SFP +
2-Port 10G SFP+ Managed Ethernet Switch |
| SFP Options | ► SFP option. Please select your SFP on our SFP Options Page |
| ► SFP module is to be purchased separately. |
| Mounting Options | ► Default DIN-Rail Bracket installed |
| Power Options | ► DIN-Rail Power Supply. Open Wire for Terminal Block. |
| ► Power Supply is to be purchased separately. |
Application Display Diagram
