Compact PIN Field Effect Transistor High Sensitivity For Fiber Optic Gyroscope

    Buy cheap Compact PIN Field Effect Transistor High Sensitivity For Fiber Optic Gyroscope from wholesalers

    Buy cheap Compact PIN Field Effect Transistor High Sensitivity For Fiber Optic Gyroscope from wholesalers
    • Buy cheap Compact PIN Field Effect Transistor High Sensitivity For Fiber Optic Gyroscope from wholesalers

    Compact PIN Field Effect Transistor High Sensitivity For Fiber Optic Gyroscope

    Ask Lasest Price
    Brand Name : Liocrebif
    Model Number : LKF-PINFET
    Certification : GJB 9001C-2017
    Price : 5000-25000CHY
    Payment Terms : T/T
    Supply Ability : 10000
    Delivery Time : 2-4 weeks
    • Product Details
    • Company Profile

    Compact PIN Field Effect Transistor High Sensitivity For Fiber Optic Gyroscope

    Essential details
    MOQ:1
    Specification Number:LKF-PINFET
    Product Introduction
    Product Introduction

    As the optical information receiver of optical receiver system, PINFET (P-Intrinsic-N Field-Effect Transistor) acts as voltage amplified optoelectronic converter.

    Specification Parameters, such as linearity response, minimum linear optical power, linear saturation optical power, 3dB bandwidth S21 are specially defined for the applications of analog optical fiber systems (for example, IFOG & FOCT et al fiber optic sensor).

    The PINFET converts the optical signal returned by the Sagnac interferometer into an electrical signal and amplifies the weak signal. In fiber optic communication systems, PINFET is usually used as digital devices, while in fiber optic gyroscopes, it is used as analog devices.


    The main requirements of fiber optic gyroscopes for PINFET components are as follows:

    1. Higher responsivity and sensitivity, smaller thermal noise and dark current noise to reduce the decrease in signal-to-noise ratio after the optical signal is converted into an electrical signal;

    2. Larger dynamic range to adapt to larger optical power input at higher signal-to-noise ratio;

    3. The frequency bandwidth meets the requirements of the gyroscope.


    Technical Specification

    LKF PINFET

    Wavelength Band

    1290 ~ 1560nm

    Linear Responsibility

    0.72 V/μW

    0.36 V/μW

    0.18 V/μW

    Linear Maximum Optical Power

    ≥4μW

    ≥8μW

    ≥16μW

    Linear Minimum Optical Power

    ≤0.03μW

    ≤0.05μW

    ≤0.1μW

    Linearity

    ±3%

    Trans-Impedance

    800KΩ

    400KΩ

    200KΩ

    3dB Bandwidth

    4~10MHz

    Root-Mean-Square (RMS) Voltage

    ≤0.5mV

    Package

    See package type

    Tail Fiber

    SM/PM, φ125μm/80μm,L=1m

    Working Temperature

    -45~+70℃

    Storage Temperature

    -55~+85℃


    Product Code Table

    Product code

    Package Type

    Trans-Impedance

    Output pigtail

    TSXF01

    8 pins

    200K

    125/250 SM Fiber

    TSXH02

    8 pins

    400k

    125/250 SM Fiber

    TFGF02

    Mini 8 pins

    200K

    80/165 SM Fiber

    TFGH01

    Mini 8 pins

    400k

    80/165 SM Fiber

    TGGF02

    Mini 6 pins

    200K

    80/165 SM Fiber

    TDXJ02

    14 pins

    800k

    125/250 SM Fiber

    Key Features

    Low Noise, High Linearity

    Bandwidth can be Adjust for DifferentResponsivity

    Compliance Of 14pins/8pins Package are Replaceable

    Excellent Consistency and Reliability

    Applications

    Fiber Optic Gyroscope (FOG)

    Fiber Optic Current Transformer (FOCT)

    Other Fiber Optic Sensing


    Fig.1 Dimensions Of PINFET

    S Type


    D Type


    F Type


    G Type
