Schneider M172 HVAC PLC Controller 28 I/O TM172PBG42RI

Schneider M172 HVAC PLC Controller TM172PBG42RI

Main Information

• Product Series: Modicon M171/M172
• Product Type: Programmable Controller
• Application Type: HVAC (Heating, Ventilation, and Air Conditioning) Control
• Variables: Programmable
• Total inputs/outputs: 28
• Number of Discrete Inputs: 8
• Number of Discrete Outputs:
  • 1 applicable, Relay Output SPDT (includes independent common points)
  • 3 applicable, Relay Output SPST (includes the same common points)
  • 2 applicable, Relay Output SPST (includes the same common points)
  • 2 applicable, Relay Output SPST (includes independent common points)
• Discrete Output Current:
  • 3 A applicable, Relay SPDT
  • 3 A applicable, Relay SPST
• Number of Analog Inputs: 8 (configurable in pairs)
• Outputs:
  • 2 Voltage, Range: 0...10 V
  • 2 Voltage/Current, Range: 4...20 mA or 0...10 V or PWM (2 kHz)

Supplementary Information

• Number of Ports:
  • 1 CAN Port - Screw Terminal
  • 1 USB (Type - A) - Type - A Female USB
  • 1 Mini - B USB - USB Device Port
  • 2 RS485 - Screw Terminals (Modbus Serial or BACnet MS/TP)
  • 1 Ethernet - RJ45 (Modbus TCP and BACnet IP with Web Server)
• Input/Output Count:
  • 8 Digital Input(s)
  • 8 Analog Input(s)
  • 4 Analog Output(s)
  • 8 Digital Output(s)
