| Brand Name : | SPR-ing |
| Model Number : | JSD-5 |
| Certification : | GB2423.1、 GB2423.2、 GJB150.3、GJB150.4、GB11158、GB10589 |
| Price : | 15000~50000 USD |
| Payment Terms : | T/T |
| Supply Ability : | 20/month |
| Delivery Time : | 1~3 weeks |
◆ Predicting the dust-resistant quality of industrial and
electronic products by artificially simulating the dusty
environment and climate
◆ The sand and dust particles are sprayed on the test sample
through the sand and dust generator, sand blasting device and other
equipment, and the sand and dust environment and test conditions
are controlled by the circulating fan and filter device.
◆ The box is used to simulate the sand and dust environment, the
sand blasting device and the circulating fan control the movement
and circulation of the sand and dust particles, the filtering
device can effectively filter the sand and dust particles, and the
sample holder is used to place the test samples.
III. Main uses
◆ The sand and dust test chamber is used to test the sealing
performance of the product shell, and is mainly used for the test
of the two levels of IP5X and IP6X of the shell protection level.
By simulating sand and dust weather, outdoor lamps, auto parts,
outdoor cabinets, power meters and other products are tested.
Model | JSD-5/6X-125 | JSD-5/6X-500 | YXHP56X-1000L | YX-IP56X-1500L |
Capacity(L) | 125 | 500 | 1000 | 1500 |
Inner size | 500x500x500mm 800x800x800mm 1000x1000x1000mm 1000x 1500×1000mm | |||
Outer size | 1450x 1720x1970mm | |||
Power | 1.0KW 1.5kw 1.5KW 2.0KW | |||
Time setting range | 0-999h adjustable | |||
Temperature setting range | RT+10~70 ° C (specify when ordering) | |||
Experimental dust | Talc powder/Alexander powder | |||
Dust consumption | 2-4kg/m3 | |||
Dust reduction method | Free powder spraying for dust reduction | |||
vacuum degree | 0-10.0kpa (adjustable) | |||
Protector | Leakage protection, short circuit protection | |||
supply voltage | 220V | |||
|
