JSSCD-70NC/P CNC High Speed Circular Saw Machine(Horizontal-Push)
Description
Contemporary industrial metal processing necessitates equipment
that simultaneously achieves high-volume output and exacting
dimensional tolerances. This CNC-driven high-speed horizontal
circular saw directly meets this dual requirement. By combining
rapid material separation capabilities, sophisticated control
technology, exceptional positional stability, and energy-conscious
operation, it becomes fundamental infrastructure for reliable,
high-quality industrial metal cutting.
Core Principles of Reliable Performance
A defining characteristic of this machine is its ability to
maintain precise dimensional control throughout extended
operational periods. This reliability stems from several integrated
engineering subsystems:
Advanced Cutting Mechanics: An AC servo motor, integrated with ball
screw drive transmission, provides exceptionally smooth and highly
regulated feed motion for the cutting head.
Robust Workholding: A multi-point hydraulic workholding system
guarantees complete material fixation during operation. Constructed
with durable, high-precision elements, it eliminates slippage under
maximum cutting loads, ensuring consistent part accuracy. This
configuration also enables rapid adaptation for varying material
dimensions or shapes, boosting operational flexibility and reducing
changeover delays.
Systems for Sustained Precision: Backlash within the servo/ball
screw assembly is rigorously controlled. Steady clamping and feed
forces are delivered by a high-capacity hydraulic unit. Enhanced
component lifespan is achieved through a dual lubrication strategy:
a programmable central lubrication system supplemented by a
pneumatic Minimal Quantity Lubrication (MQL) unit for targeted
micro-lubrication and blade cooling, substantially lowering wear
and extending service intervals. Workspace debris removal and
safety are enhanced by a magnetic chip extraction system utilizing
a hollow rotary actuator. A tungsten-carbide component separator
guarantees clean part ejection post-cut.
Specifications:
| Model | Unit | JSSCD-70NC/P |
| Mainframe dimensions | mm | 2250*1790*1760 |
| Bar & round pipe | mm | 10-70 |
| Angle bar & square bar | mm | 10-60 |
| Saw blade size | mm | φ285*2.0*φ32 |
| Pin holes and hole diameters | mm | 4*φ11*63 φ32 |
| Spindle motor power | KW | 7.5(4P) |
| Spindle speed | rpm | 20-168 |
| Feed servo motor power | KW | 1.5 |
| Feeding servo motor power | KW | 1.5 |
| Material removal length at the front end | mm | 10-99 |
| Single feeding length(repeatable) | mm | 6-860 |
| Hydraulic drive motor power | KW | 1.5(4P) |
| Rated pressure of the hydraulic system | mpa | 5.5 |
| Hydraulic oil capacity | L | 70 |
| Cut off feed mode |
| AC servo motor & ball screw / horizontal entry |
| Main clamping method |
| Hydraulic type / one set each for horizontal and 15° |
| Saw blade debris removal device |
| Passive/active circular wire brush (optional) |
| Gear backlash compensation device |
| Hollow external rotating magnetic powder brake |
| Feeding drive mode |
| AC servo motor & ball screw |
| Feeding clamp method |
| Hydraulic type/Horizontal clamping |
| Residual material length at the rear end | mm | 90&a(a represents the length less than one cut-off workpiece) |
| Self-lubrication oil system |
| Timed and quantitative forced oil supply |
| Micro-lubrication system for cutting |
| Quasi-dry intermittent oil supply |
| Material separating device |
| Pneumatic reciprocating |
| Long material receiving device |
| Optional |
| Blade swing anti-vibration device |
| Tungsten carbide parallel block |
Streamlined Operation via Advanced Control
Central to the machine is its dedicated PRECISION CNC CONTROL
PLATFORM. This advanced unit meticulously manages critical cutting
parameters including velocity and angular orientation, guaranteeing
efficient and accurate results for every workpiece. Operation is
simplified through an intuitive Human-Machine Interface (HMI).
Personnel can easily input job specifications and manage an
extensive library of cutting programs via a user-centric console,
achieving significant automation. This markedly reduces operator
workload and minimizes risks linked to manual configuration errors.
FAQ
Q1: Are you a manufacturer or a trading company?
A:We are a professional manufacturer of saw blade grinders. We have a
30,000 square meter factory and a team of dedicated technicians
specializing in design, manufacturing, and sales.
Q2. Where is your factory located?
A:Our factory is located in Nantong City, Jiangsu Province, China.
It will takes about 1.5 hours from Shanghai Hongqiao station to our
city
Q3: What is your factory acceptance test method?
A: You can send us sample material to be cut, and we will perform a
test cut using our machine. After the test is complete, we will
provide you with detailed cutting data. (We will also send you a video of the machine cutting operation for
your confirmation.)
Q4:What is your method of transaction?
A:We adopt the FOB(Free ON Board) transaction.
Q5: How about your delivery time?
A: Generally, it will take 7-60 work days after receiving your order.
The specific delivery time depends on the items and the quantity of
your order.
Q6:How about the payment term
A:T/T 30% deposit, 70% of balance paid before shipment. (For other payment methods please contact our sales team)
Q7:Does the band saw blade have any international certifications?
A:Yes,we have obtained CE,ISO international certification.
