2.4/5.8 GHz 8dbi MIMO Omnidirectional Antenna 2400 To 2500 MHz / 5150 To 5850 MHz

    Buy cheap 2.4/5.8 GHz 8dbi MIMO Omnidirectional Antenna 2400 To 2500 MHz / 5150 To 5850 MHz from wholesalers

    Buy cheap 2.4/5.8 GHz 8dbi MIMO Omnidirectional Antenna 2400 To 2500 MHz / 5150 To 5850 MHz from wholesalers
    • Buy cheap 2.4/5.8 GHz 8dbi MIMO Omnidirectional Antenna 2400 To 2500 MHz / 5150 To 5850 MHz from wholesalers

    2.4/5.8 GHz 8dbi MIMO Omnidirectional Antenna 2400 To 2500 MHz / 5150 To 5850 MHz

    Ask Lasest Price
    Brand Name : WSD
    Model Number : FTQ-2458MQX0808V6AN
    Certification : no have
    Price : $50~300
    Payment Terms : L/C,T/T
    Supply Ability : 500
    Delivery Time : 30 work days
    • Product Details
    • Company Profile

    2.4/5.8 GHz 8dbi MIMO Omnidirectional Antenna 2400 To 2500 MHz / 5150 To 5850 MHz

    MIMO Omnidirectional Antenna 2400 to 2500 / 5150 to 5850 MHz
    • Model: FTQ-2458MQX0808V6AN
    • Name: MIMO Omnidirectional Antenna
    • Freq.Range: 2400 to 2500 / 5150 to 5850 MHz
    Communications System

    2.4/5.8GHz WLAN/WIFI/ISM/WIMAX,Spread Spectrum Communication

    Application Scenario
    • Point to multipoint,Base station antenna
    • Wireless data and image transmission
    • Outdoor signal omnidirectional coverage
    • Public wireless hotspot coverage
    • IEEE802.11a/b/e/g/n
    Electrical Specifications
    Electrical Specifications
    Freq.Range-MHz2400 to 25005150 to 5850
    Bandwidth-MHz100700
    PolarizationVerticalVertical
    Gain-dBi88
    Half-power beam width-°H:360 E:17H:360 E:17
    Cross-pol-isolation-dB≥25
    Impedance-Ω50
    VSWR≤ 1.5≤ 2.0
    Max.Power-W20
    Mechanical Specifications
    Connector6*N Female
    Connector QuantityThree 2.4GHz Connector and Three 5.8GHz Connector
    Connector PositionBottom
    Dimension-MMAbout Φ145*320
    Weight-KGAbout 1.2
    Radome materialABS or PC
    Radome colorWhite
    Operational Temperature-℃-40 to 60
    Storage Temperature-℃-55 to 85
    Relative Humidity-%5 to 95
    Rated Wind Velocity-M/S60
    Mounting wayMast
    Mast Diameter-MMΦ40 to 50
    Quality 2.4/5.8 GHz 8dbi MIMO Omnidirectional Antenna 2400 To 2500 MHz / 5150 To 5850 MHz for sale
