    High Perfomance Sanitary Napkin Production Line 1200pcs/min Eco-Friendly

    Ask Lasest Price
    Brand Name : WOMENG
    Model Number : WM-ESS04
    Certification : CE,ISO9001
    Price : $350000~$500000
    Payment Terms : L/C,T/T
    Supply Ability : 12sets/year
    Delivery Time : 90-120 days
    • Product Details
    • Company Profile

    High Perfomance Sanitary Napkin Production Line 1200pcs/min Eco-Friendly


    Key Specifications
    Production Speed800-1200 pieces per minute
    Product Size240mm,290mm,320mm,420mm(Customized according to customer requirement)
    Production Yield Rate≥98%
    WeightAbout 50 tons
    Machine Size25x4x3m
    Safety SystemIt has safety device on the operating side, matched with urgent stop switch.High audio fan uses sound insulation or silencer.
    Raw MaterialFluff pulp, SAP, non-woven fabric, PE film
    Control SystemPLC control system(Mitsubishi),HMI Operating on the LED touch
    Drive systemServo Drive(Easy to change size), timing belt and flat belt are import products, and all the key parts, are import bearings.
    Power240V,50Hz,3 Phase Five Wire


    Technical features:

    * Compact design, easy operation & maintenance
    * Modular design, for future upgrading
    * Low consumption, high efficiency
    * Servo or frequency inverter transmission
    * Touch screen for man-machine conversation
    * Auto record and calculation of process data
    * Main raw material auto splicing at zero speed
    * Inverter or servo unwinding with tension control
    * Web guiding controller
    * Sensor quality control systems
    * Material broken and lost inspection, auto machine stops and defective products auto rejection
    * Easy size changing and manufacture


    Sanitary Pad: Detailed Structure & Material Parameters Table

    Core StructureSub-StructureMain MaterialsKey Features
    Surface LayerSkin-Friendly LayerCombed Cotton,Bamboo FiberSoft, skin-friendly, breathable

    Breathable LayerMicroporous Non-Woven FabricMoisture-wicking, reduces stuffiness
    Distribution LayerRapid Penetration LayerHigh-Puff Non-Woven FabricFast liquid absorption, no local accumulation

    Despersion LayerPatterned Non-Woven FabricEven liquid distribution
    Absorbent CoreSAP Locking LayerSuper Absorbent Polymer (SAP)High water absorption, anti-reverse osmosis

    Support LayerFluff Pulp, Hollow FiberHigh water absorption, anti-reverse osmosis
    Leak-Proof BottomPE Breathable FilmPolyethylene Breathable FilmWaterproof, breathable

    Anti-Slip AdhesiveMedical-Grade AdhesiveSecure fit, no displacement
    WingsFixing WingsRigid Non-Woven FabricAnti-side shift

    Leak-Proof EdgesElastic Non-Woven FabricEnhanced side leakage protection
    Machine Panoramic Image


    Contact Information
    Whatsapp: +008615805080212


    Costs are controllable, enhancing the long-term profit margin
    Low-loss production design:
    In key processes (such as core laying, surface layer cutting, and glue volume control), precise positioning and parameter locking technologies are adopted, keeping the raw material loss rate at a relatively low level in the industry (usually below 3%). Take a production line with an average daily capacity of 50,000 pieces as an example. It can reduce the waste of nearly 55,000 pieces of raw materials each year. Calculated at a cost of 0.1 US dollars per piece of raw material, it can save an average of 5,500 US dollars in costs annually. In the long run, it will significantly lower your production costs.

    Flexible investment model:
    Supports a phased investment plan of "basic production capacity + module expansion". In the initial stage, core production modules can be introduced first (to meet the production needs of daily and night basic models), which will have a lower investment cost. If the market demand grows in the future, additional workstations (such as independent packaging modules, fragrance addition modules, and ventilation hole processing modules) can be installed at any time without the need to rebuild the production line, avoiding the financial pressure brought by a large one-time investment. It is especially suitable for small and medium-sized customers to gradually expand their business.
