Product Description:
The core design goal of the DG4V series solenoid valve is to
efficiently and reliably control the direction of hydraulic oil
flow, thereby driving the action of actuating components such as
oil cylinders and hydraulic motors. Its main technical features and
attributes include:
- High working pressure and flow rate: The maximum working pressure
of this series of valves can reach 350 bar (approximately 5075
psi), and the maximum pressure in the fuel tank pipeline is 210 bar
(approximately 3045 psi). The rated flow can reach 80 L/min and 40
L/min respectively at a pressure of 350 bar, which can efficiently
control large hydraulic power.
- Compliant with international standards and compact design: The
installation interface complies with ISO 4401-03 standard, ensuring
interchangeability and compatibility with other hydraulic
components. The valve adopts a compact design with high
power/weight ratio and power/volume ratio, which helps to save
installation space and costs.
- Excellent durability and reliability: The valve core adopts a
stainless steel structure, which improves the anti-corrosion
ability. The standard configuration of the seal is Viton, which can
adapt to various oils (including petroleum based oils, water
ethylene glycol, water in oil emulsions, and phosphate ester oils
and their mixtures). Nitrile rubber (NBR) seal can be used as
option 15. Its fatigue life and durability have been verified
through over 20 million cycles of testing.
- Easy to install and maintain: The coil can be quickly replaced
without disassembling the valve or leaking hydraulic oil. Can work
with Eaton's SystemStake ™ Combination of stacked valves and base
plates to build a compact system.
Applications:
The DG4V series solenoid valve is widely utilized across various industries that demand
high-performance hydraulic control owing to its dependable
performance.
Industrial machinery: extensively used in industrial equipment like CNC machine tools,
injection molding machines, die-casting machines, presses, etc.,
for regulating the movement direction of oil cylinders or hydraulic
motors to achieve precise process flow.
Construction machinery and mobile equipment: within the hydraulic systems of construction machinery such as
excavators and loaders, it is employed for controlling the action
switching of actuators like the boom and bucket to realize complex
composite actions.
Mining and Heavy Equipment: ideal for rugged working environments such as mining machinery
(e.g., crushers, conveyors), its robust design can endure dust,
vibration, and high loads.
Ship and Port Machinery: utilized in hydraulic control systems for ship deck machinery like
winches and cranes, as well as port lifting equipment. Its
corrosion-resistant design can adapt to high humidity and high
salinity environments at sea.
Other important fields: moreover, it finds application in metallurgical equipment, the
wind power industry, aerospace, and other sectors with stringent
requirements for hydraulic systems.
Support and Services:
Our Product Technical Support and Services for the Solenoid Valve
include:
- Expert troubleshooting assistance for any issues with the
solenoid valve
- Guidance on installation, operation, and maintenance of the valve
- Access to product manuals, user guides, and technical
specifications
- Warranty information and support for product replacements or
repairs
Packing and Shipping:
Product Packaging:
The Solenoid Valve is carefully packaged to ensure safe delivery.
Each valve is wrapped in protective material and placed in a sturdy
cardboard box with ample cushioning to prevent any damage during
transit.
Shipping:
Orders for the Solenoid Valve are processed within 1-2 business
days. We offer standard and expedited shipping options to
accommodate your needs. Once your order has been shipped, you will
receive a tracking number to monitor the delivery status of your
package.
