Schneider Electric LR9D5369 TeSys LRD Thermal Overload Relays 90-150A Class 10 For NSX Circuit Breaker

    Buy cheap Schneider Electric LR9D5369 TeSys LRD Thermal Overload Relays 90-150A Class 10 For NSX Circuit Breaker from wholesalers

    Buy cheap Schneider Electric LR9D5369 TeSys LRD Thermal Overload Relays 90-150A Class 10 For NSX Circuit Breaker from wholesalers
    • Buy cheap Schneider Electric LR9D5369 TeSys LRD Thermal Overload Relays 90-150A Class 10 For NSX Circuit Breaker from wholesalers
    • Buy cheap Schneider Electric LR9D5369 TeSys LRD Thermal Overload Relays 90-150A Class 10 For NSX Circuit Breaker from wholesalers
    • Buy cheap Schneider Electric LR9D5369 TeSys LRD Thermal Overload Relays 90-150A Class 10 For NSX Circuit Breaker from wholesalers
    • Buy cheap Schneider Electric LR9D5369 TeSys LRD Thermal Overload Relays 90-150A Class 10 For NSX Circuit Breaker from wholesalers

    Schneider Electric LR9D5369 TeSys LRD Thermal Overload Relays 90-150A Class 10 For NSX Circuit Breaker

    Ask Lasest Price
    Brand Name : Schneider Electric
    Model Number : LR9D5369
    Certification : COO & COC
    Price : $250
    Payment Terms : T/T,Alipay,Paypal
    Supply Ability : 99+
    Delivery Time : 3-5 days
    • Product Details
    • Company Profile

    Schneider Electric LR9D5369 TeSys LRD Thermal Overload Relays 90-150A Class 10 For NSX Circuit Breaker

    Schneider Electric LR9D5369 TeSys LRD thermal overload relays 90-150A Class 10 for NSX circuit breaker


    Product Description
    The Schneider Electric LR9D5369 is a high-performance Class 10 thermal overload relay from the TeSys LR9D family, engineered to protect three-phase asynchronous motors against overload, phase-loss and unbalanced currents. Rated for 90–150 A at 690 V AC, it delivers precise trip timing, manual and automatic reset options, and direct DIN-rail or contactor mounting for fast panel integration.
    Key Specifications
    • Rated Current Range: 90–150 A (adjustable dial)
    • Trip Class: 10 (±10 % tolerance)
    • Insulation Voltage: 690 V AC (pollution degree 3)
    • Breaking Capacity: 100 kA @ 690 V with appropriate contactor
    • Ambient Temperature: –20 °C … +60 °C (no derating up to 40 °C)
    • Reset Mode: Manual (blue button) or automatic selector
    • Auxiliary Contacts: 1 NO (95-96) + 1 NC (97-98) as standard
    • Mounting: Clip-on to LC1D series contactors or standalone 35 mm DIN rail (LA7D3064 bracket)
    • Certifications: CE, UL 508, CSA, IEC 60947-4-1, RoHS
    Typical Applications
    • Centrifugal pumps & compressors
    • Conveyor belts and material handling systems
    • HVAC fan motors (110 kW / 150 HP @ 400 V)
    • Retrofits replacing LR1D/LR9D older versions
    Benefits
    • Space-saving: Same footprint as LC1D contactors reduces panel depth
    • Reliability: Bi-metal strip technology ensures repeatable trip curves
    • Safety: IP20 finger-safe terminals and clear trip indication window

    • Maintenance: Tool-free reset and test button for rapid diagnostics

    Product Details Pictures
