    TPS62170DSGR Step-Down Converter 3-17V Input 1.2A Output Up to 95% Efficiency 1.8V to 6V Adjustable Output 17μA Low Quiescent Current Power Save Mode 100% Duty Cycle Small 2.0x2.0mm WSON Package

    TPS62170DSGR Step-Down Converter 3-17V Input 1.2A Output Up to 95% Efficiency 1.8V to 6V Adjustable Output 17μA Low Quiescent Current Power Save Mode 100% Duty Cycle Small 2.0x2.0mm WSON Package


    Features

    • DCS-Control™Topology

    • InputVoltageRangefrom3Vto17V

    • Upto500-mAOutputCurrent

    • AdjustableOutputVoltagefrom0.9Vto6V

    • FixedOutputVoltageVersions

    • SeamlessPowerSaveModeTransition

    • Typically17-µAQuiescentCurrent

    • PowerGoodOutput

    • 100%DutyCycleMode

    • ShortCircuitProtection

    • OverTemperatureProtection

    • PintoPinCompatiblewithTPS62160and TPS62125

    • Availableina2-mm×2-mm8-PinWSON Package


    Applications

    • Standard12-VRailSupplies

    • POLSupplyfromSingleorMultipleLi-IonBattery

    • LDOReplacement

    • EmbeddedSystems

    • DigitalStillCamera,Video

    • MobilePCs,Tablet-PCs,Modems


    Description

    The TPS6217x device family are easy to use synchronousstep-downDC-DCconvertersoptimized for applications with high power density. A high switchingfrequencyof typically2.25MHzallows the use of small inductors and provides fast transient responseaswellashighoutputvoltageaccuracyby utilizationof theDCS-Control™topology.

    With itswideoperating input voltagerangeof3Vto 17 V, the devices are ideally suited for systems poweredfromeitheraLi-Ionorotherbatteryaswell asfrom12-Vintermediatepower rails. Itsupportsup to0.5-Acontinuousoutputcurrentatoutputvoltages between0.9Vand6V(with100%dutycyclemode).

    Powersequencingisalsopossiblebyconfiguringthe enableandopen-drainpowergoodpins.

    In power savemode, the devices showquiescent currentofabout17μAfromVIN.Powersavemode, enteredautomaticallyandseamlessly if the load is small,maintainshighefficiencyover theentire load range. In shutdownmode, thedevice is turnedoff andshutdowncurrentconsumptionislessthan2μA.

    Thedevice, available inadjustableand fixedoutput voltageversions, ispackaged ina2-mm×2-mm8 pinWSONpackage(DSG).
