    Buy cheap 1.7 W 500 V a.c. ABB AI820 3BSE008544R1 Analog Input Module Digital I O Module
 from wholesalers

    Buy cheap 1.7 W 500 V a.c. ABB AI820 3BSE008544R1 Analog Input Module Digital I O Module
 from wholesalers
    • Buy cheap 1.7 W 500 V a.c. ABB AI820 3BSE008544R1 Analog Input Module Digital I O Module
 from wholesalers
    • Buy cheap 1.7 W 500 V a.c. ABB AI820 3BSE008544R1 Analog Input Module Digital I O Module
 from wholesalers

    1.7 W 500 V a.c. ABB AI820 3BSE008544R1 Analog Input Module Digital I O Module

    Ask Lasest Price
    Brand Name : ABB
    Model Number : AI820
    Price : Negotiations
    Delivery Time : 2-3 working days
    • Product Details
    • Company Profile

    1.7 W 500 V a.c. ABB AI820 3BSE008544R1 Analog Input Module Digital I O Module

    1.7 W 500 V a.c. ABB AI820 3BSE008544R1 Analog Input Module Digital I O Module



    Detailed data:


    Resolution

    14 bit plus sign

    Input impedance

    200 kΩ ± 25% (voltage mode, common mode)
    800 kΩ ± 25% (voltage mode, normal mode)
    250 Ω (current input)

    Isolation

    Groupwise isolated from ground (RIV=50 V)

    Under/over range

    ± 15%

    Error

    Max. 0.1%

    Temperature drift

    Voltage: Max. 70 ppm/°C Current: Max. 50 ppm/°C

    Input filter (rise time 0-90%)

    40 ms

    Current limiting

    Transmitter power can be current limited by the MTU

    Maximum field cable length

    600 meters (656 yards)

    Dielectric test voltage

    500 V a.c.

    Power dissipation

    1.7 W

    Current consumption +5 V Modulebus

    80 mA

    Current consumption +24 V Modulebus

    0

    Current consumption +24 V external

    70 mA


    Diagnostics:


    Front LED’s

    F(ault), R(un), W(arning)

    Supervision

    Internal Power Supply

    Status indication of supervision

    Modul



    General info:


    Type

    Analog Input

    Signal specification

    -20..+20 mA, 0(4)..20 mA, -10..+10 V, 0(2)..10 V

    Article number

    3BSE008544R1

    Number of channels

    4

    Signal type

    Bipolar differential

    HART

    No

    SOE

    No

    Redundancy

    No

    High integrity

    No

    Intrinsic safety

    No

    Mechanics

    S800




    Dimensions:


    Height

    119 mm (4.7”)

    Width

    45 mm (1.77”)

    Depth

    102 mm (4.01”), 111 mm (4.37”) including connector

    Weight

    0.2 kg (0.44 lbs.)
