Customized ISO13485 Medical PCB Assembly Services from Custom PCBA
Manufacturer with Full Turnkey Solutions
Ring PCB offers professional medical device PCB assembly (PCBA) solutions designed for handheld automation equipment and display
driver boards. With 17 years of industry expertise, we deliver customized PCBA and full turnkey services that meet strict international medical standards such as ISO13485.
Our high-quality medical PCB assembly ensures reliability, precision, and performance for global
customers.
1.Key Features & Advantages
High Reliability: All PCBs and PCB assemblies meet ISO9001, ISO14001, ISO13485, and IATF16949 standards.
Fast Prototyping: 3-day rapid sample making, 7-day batch production.
Customization: Tailored PCBA for medical devices, supporting both low-volume and high-volume production.
Global Reach: Products exported to 50+ countries with proven customer
satisfaction.
Full Turnkey Service: From PCB fabrication, component sourcing, SMT, through-hole
assembly, testing, and final box build.
2.Solving Technical Challenges
Medical PCBs demand high reliability, EMI/EMC control, precise signal integrity, and
biocompatibility compliance. At Ring PCB, our engineering team applies advanced DFM (Design for Manufacturability) and DFT (Design for Testability) strategies. With modern production facilities in Shenzhen and
Zhuhai (over 5000㎡), we ensure:
High-precision soldering for fine-pitch ICs and BGA packages.
Strict ESD protection and cleanliness controls for medical safety.
Comprehensive testing (ICT, AOI, X-ray, functional test) to guarantee product quality.
Reliable component traceability to meet international regulatory requirements.
3.Common Technical Specifications
| Parameter | Capability / Range |
|---|
| Board Type | Multilayer PCB, Rigid, Rigid-Flex |
| Layer Count | 2–24 layers |
| Copper Thickness | 0.5 oz – 6 oz |
| Min. Line Width/Spacing | 3 mil / 3 mil |
| Surface Finish | ENIG, HASL, OSP, Immersion Silver/Tin |
| Solder Mask | Green, Blue, Black, White, Custom |
| Assembly Capability | SMT, THT, Mixed, BGA, QFN, Fine-Pitch IC |
| Testing | AOI, ICT, X-ray, Functional Test |
| Standards Compliance | ISO13485, RoHS, REACH, IPC Class 2/3 |
4.Application field:
Handheld medical monitoring devices
Portable diagnostic equipment
Patient data collection systems
Display driver boards for automation and imaging
Smart wearable medical instruments
Why Choose Ring PCB?
Core Competencies & Advantages of Ring PCB Technolog
1. Direct Factory Pricing & Transparent Manufacturing
◦ Owned Shenzhen factory ensures source-level cost control and
eliminates middleman markups.
◦ Invitation for factory visits to witness advanced equipment (e.g.,
automated SMT lines) and rigorous production processes firsthand.
2. One-Stop PCB & PCBA Expertise for End-to-End Solutions
◦ Comprehensive services from 2-48 layer PCB fabrication to
components sourcing, SMT assembly, and full turnkey projects,
eliminating the need for multiple vendors.
◦ 17+ years of industry experience (since 2008) with 500+ skilled
employees, delivering 5,000+ electronic projects for 3,000+ global
clients.
3. Stringent Quality Control with Advanced Inspections
◦ Multi-stage quality assurance: SPI 3D, AOI, LCR testing, and X-Ray
for BGA components ensure zero-defect products.
◦ Certified compliance: IPC standards, RoHS, UL, ISO
9001/14001/13485, IATF16949—meeting medical, automotive, and
industrial safety requirements.
4. Industry-Leading Capabilities & Customization
Specialized in high-frequency, heavy copper, and complex PCBs for
demanding sectors: communication base stations, medical devices, EV
charging stations, robotics, etc.
Tailored solutions for unique projects—from prototype to mass
production, with rapid turnaround supported by in-house Shenzhen
factory.
5. Reliable Partner for Diverse Applications
Wide industry coverage: Security, industrial control, drones,
servers, and more—proven track record in critical sectors requiring
high reliability.
Incoming material inspection, real-time process monitoring, and
final QC guarantee on-time delivery with consistent performance.
Ring PCB not only offers professional PCB manufacturing, but also offer
PCBA service, including component sourcing and SMT service with
Samsung functional machine.
Convenience: One-stop service reduces supply chain complexity.
Quality: Certifications and multi-inspections ensure product
reliability.
Speed: In-house production enables fast prototyping and delivery.
Cost-Effectiveness: Direct factory pricing with no compromise on
quality.
Expertise: 17+ years supporting global clients across diverse
industries.
Partner with Ring PCB Technology—where 17 years of expertise,
end-to-end services, and certified quality meet your unique needs.
Whether for prototyping or mass production, our Shenzhen factory
ensures precision, speed, and factory-direct pricing. Contact us
today to discuss your requirements !
Other customized medical device pcba:
Please note:
All products in our store are processing customized services,
please be sure to contact our professional customer service before
placing an order to confirm the product details.
All photos on this site are real. Due to changes in lighting,
shooting Angle, and display resolution, the image you see may have
some degree of chromatic aberration. Thank you for your
understanding.
Ring PCB Technology Co.,Limited is a professional PCB manufacturer with 17 years of history in
China. Our products are updated and upgraded every year and We
specialize in all kinds of PCB making and PCBA customization
services, If you are interested in our products, please tell us
your requirements, we will help you to provide professional
solutions, please contact us on line or E-mail to us, and we will provide you with one-on-one service from our
professional sales team.Thank you for your time.
We are committed to helping you bring your medical innovations to
life with high-quality medical device PCB assembly services.
