Barcode Qr Code Scanner Suppliers Barcode Reader Embedded 1d 2d OCR Mrz Scanner Module
Features of Embedded 1D/2D Barcode Scanners
Easily read a wide range of mainstream lD and standard 2Dbarcodes (PDF 417,QR Code Model 1/2,Hanxin code ,
Maxicode,Aztec, Micro QR and Data Matrix versions).lt also supports readingGS1-DataBarTM(RSS) barcodes,including
Limited, Stacked,Expanded and other versions.
Application scenarios of fixed scanners
Embedded into various terminal devices, such as self-service payment in unmanned vending machines, self-service inquiry
terminals, logistics express cabinets, intelligent number dispensers, unmanned ticket machines, POS payment systems, and
other IoT industry chain applications.
|
Capability
|
|
Collection method
|
Image type, CMOS Sensor
|
|
Picking rate
|
1 / 60 Seconds
|
|
Field of view Angle
|
Horizontal 62°, and 48.5° vertical
|
|
Ability to read
|
|
Identification accuracy
|
≥5mil
|
|
Read the way
|
Close to, close to the reading
|
|
Scan the Angle
|
The rotation angle was 360°, elevation angle ± 55°, and bias angle ± 55°
|
|
Support code system
|
In line with the international and domestic general QR code standards:
QR Code, PDF417, DataMatrix (ECC200), etc
In line with the international and domestic general one-dimensional code standards:
EAN 13, EAN 8, UPC-A, UPC-E0, UPC-E1, Code128, Code39, Code93, CodaBar, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code11,MSI Plessey, RSS-14, qualified RSS, extended RSS, etc
|
|
Print contrast
|
Minimum 25% of the reflection difference
|
|
LED
|
|
Fill-in light
|
White
|
|
Physical parameters
|
|
size
(Long, width and height)
|
61mm ×51mm ×16.4mm
|
|
Weight
|
Less than 30g
|
|
Joggle
|
|
Joggle
|
4 PIN cable socket: USB KBW
4 PIN cable socket: Serial port TTL 232 or RS232 (5V or 3.3V)
|
|
Scan pattern
|
Command mode / induction mode / trigger mode
|
|
Read success tips
|
The LED and the buzzer
|
|
Data line (optional)
|
4PIN straight line
|
FAQ
Q: Can you send a sample?
A: Yes, YJFIRST welcomes sample orders to test. Please contact us for more details before placing a sample order.
Q: Can we have our logo or company name printed on the product or package?
A: Yes, printing with the logo or company name is acceptable; it will be accomplished by silk printing. Please contact us
for more details.
Q: What's the shipping method?
A: There are DHL, FedEx, TNT, and UPS. We can also ship the goods using your shipping account or other express
agents you provide.
Q: What's the payment method?
A: We accept online orders, PayPal, T/T, LC, Western Union, and MoneyGram.
Q: How about your product warranty?
A: Our formal guarantee period is one year after delivery.
Q: How is your quality control?
A: We have a professional QC team and testing machines (engine age testing, wire bending machine, switch life testing, shock
resistance testing). CE, FCC & ROHS certified.
Q: If I come across any problems during product use, where can I get support?
A: We provide technical support 24/7. Please send all your questions to us and we will give you professional and patient
explanations via email or call in time.
