10.1" touch kiosk RFID NFC reader bulit-in QR scanner for self-payment Check-in machine Attendance machine Access control system

    Buy cheap 10.1

    Buy cheap 10.1
    • Buy cheap 10.1
    • Buy cheap 10.1
    • Buy cheap 10.1
    • Buy cheap 10.1
    • Buy cheap 10.1
    • Buy cheap 10.1

    10.1" touch kiosk RFID NFC reader bulit-in QR scanner for self-payment Check-in machine Attendance machine Access control system

    Ask Lasest Price
    Brand Name : ITD/OEM
    Model Number : ITD101PPCT5Kxx-RFID/NFC
    Certification : CE, FCC, RoHS
    Price : TBA
    Payment Terms : T/T
    Supply Ability : 10000PCS/Month
    Delivery Time : 12-15 Business Days
    • Product Details
    • Company Profile

    10.1" touch kiosk RFID NFC reader bulit-in QR scanner for self-payment Check-in machine Attendance machine Access control system

    10.1" touch kiosk RFID NFC reader bulit-in QR scanner for self-payment Check-in machine Attendance machine Access control system

    ITD 10.1” zero-bezel PCAP touch panel PC with an integrated RFIC/NFC reader represents a sleek and modern interface solution for various applications. The zero-bezel design eliminates the raised edges typically found around the screen, providing a seamless and elegant look that enhances both aesthetics and usability by allowing edge-to-edge touch functionality. The PCAP technology offers high accuracy, multi-touch capabilities, and robust durability, making it ideal for interactive displays and kiosks. Integrating an RFIC/NFC reader adds the capability for secure, contactless communication and data exchange, enabling functionalities such as access control, payment processing, and user identification. This combination of features creates a versatile, efficient, and user-friendly device suitable for retail, hospitality, healthcare, and other industries that demand advanced touch interfaces and secure wireless interactions.


    Specs:

    Panel

    Cell Type/Glass Surface

    TFT

    Size/ Aspect Ratio

    10.1”/16:10

    Active Area/ Pixel Pitch

    216.96(H) ×135.6(V)mm/0.1695 × 0.1695mm

    Native Resolution/ Colors

    1280×800/16.7M

    Brightness/ Contrast

    350cd/(500~1000 cd/optional)/800:1

    Response Time/ Viewing Angle(Typical)

    25ms/85/85/85/85

    Light Source

    LED Backlight with 30000Hours’Lifetime

    SYSTEM

    Item

    ARM Solution

    X86 Solution 1

    X86 Solution 2

    CPU

    ARM Quad Core Cortex-A17 RK3288, 1.8GHz (RK3399/RK3568/RK3576/RK3588 optional)

    Intel® Celeron J1900/J4125/J6412 2.0GHz

    Intel® Core i3/i5/i7

    (4th~14th Generation optional)

    Chipset

    Rockchip

    Intel Bay Trail SoC

    Intel SoC Chipset

    Memory

    2GB; 4GB/8GB Optional

    Dual Channel, DDR3 1333/1600MHz Memory,

    Max.8GB; DDR4 SODIMM×1(Intel J4125/J6412)

    2×DDR3 1333/1600MHz SO-DIMM Slot, Max. 16GB

    DDR4 SODIMM ×2 (8th~14th gen.)

    DDR5 optional (12th Gen. or Newer)

    Storage

    8GB; 16GB/32GB/64GB/128G Optional

    1×mSATA, 1×SATA

    1×M.2 (not available for J1900) Default to 64GB SSD

    1×mSATA, 1×SATA

    1×M.2 Default to 64GB SSD

    Graphics

    Supports max. 4K resolution

    Intel HD/UHD Graphics (By CPU)

    Intel HD/UHD Graphics (By CPU)

    I/O

    1 × HDMI; 2 × USB Max. 4× USB; 1 × USB OTG(Optional); 1 × COM(Optional);

    1 × TF Card Support 8~128GB

    1×VGA Output; 1×HDMI Output; 2×USB 3.0; 2×USB 2.0 max. 6; 2×COM port max. 6; 1×Realtek ALC662

    Line-Out /MIC IN

    1×VGA Output; 1×HDMI Output; 2×USB 3.0; 2×USB 2.0 max. 6; 2×COM max. 6; 1×Realtek ALC662

    Line-Out /MIC IN

    LAN

    1×10/100/1000Mbps Ethernet

    1× 10/100/1000Mbps Ethernet(Dual LAN optional)

    1×10/100/1000Mbps Ethernet(Dual LAN optional)

    OS

    Android 7.1/8/10/11/12/13/14, etc.

    Linux Ubuntu(optional)

    Windows 7/10, Linux

    Windows 11(available for J4125/J6412)

    Windows 7/10, Linux

    Windows 11(available for 8th gen. or above)

    GENERAL

    Power

    Input Voltage

    DC 12V (DC9~36V input, AC110~240V input optional)

    Operation/Power Saving

    10~35W

    Environment Considerations

    Operating Temperature

    -10~60

    Storage Temperature

    -20~70

    Relative Humidity

    10%~90% (non-condensing)

    Order Information

    10.1” Zero Bezel Panel PC with PCAP Touch RK3288/ITD101PPCT5KE1-RFID/NFC

    10.1” Zero Bezel Panel PC with PCAP Touch RK3568/ITD101PPCT5KE3-RFID/NFC

    10.1” Zero Bezel Panel PC with PCAP Touch RK3588/ITD101PPCT5KE4-RFID/NFC

    10.1” Zero Bezel Panel PC with PCAP Touch J1900/ITD101PPCT5KJ1-RFID/NFC

    10.1” Zero Bezel Panel PC with PCAP Touch J4125/ITD101PPCT5KJ4-RFID/NFC

    10.1” Zero Bezel Panel PC with PCAP Touch J6412/ITD101PPCT5KJ6-RFID/NFC

    10.1” Zero Bezel Panel PC with PCAP Touch i3/ITD101PPCT5KI3-RFID/NFC

    10.1” Zero Bezel Panel PC with PCAP Touch i5/ITD101PPCT5KI5-RFID/NFC

    10.1” Zero Bezel Panel PC with PCAP Touch i7/ITD101PPCT5KI7-RFID/NFC

    10.1” Zero Bezel Panel PC with Tempered Glass No Touch /ITD101PPCG1Kxx-RFID/NFC
