    BAS16W 100V 200mA Switching Diode with 4ns Reverse Recovery Dual Series Configuration SOT-323 Package and Tape & Reel Packaging for High-Speed Circuit Design

    Ask Lasest Price
    Brand Name : NXP
    Model Number : BAS16W
    Certification : CE, GCF, ROHS
    Price : Negotiable
    Payment Terms : T/T, Western Union,
    Supply Ability : 1000pcs per month
    Delivery Time : 3-5 working days after received the payment
    • Product Details
    • Company Profile

    BAS16W 100V 200mA Switching Diode with 4ns Reverse Recovery Dual Series Configuration SOT-323 Package and Tape & Reel Packaging for High-Speed Circuit Design

    BAS16W 100V 200mA Switching Diode with 4ns Reverse Recovery Dual Series Configuration SOT-323 Package and Tape & Reel Packaging for High-Speed Circuit Design


    Features

    Very high switching speed

    Low junction capacitance

    Low leakage current

    Compliant to RoHS (w/o exemp.)

    REACH, Conflict Minerals *)


    Applications

    Signal processing,High-speed

    Switching, Rectifying

    Commercial /industrial grade ')

    Suffix -Q: AEC-Q101 compliant ')

    Suffix -AQ: AEC-Q101 qualified ')


    Description

    The BAS16W is a dual series-configuration general-purpose switching diode in a SOT-323 package, designed for high-speed switching applications. lt features a high reverse breakdown voltage of 100V and a continuous forward current capability of 200mA, ensuring stable performance in high-frequency circuits. With an ultra-fast reverse recovery time (4ns), it significantly reduces switching losses and improves system efficiency.

    The dual series configuration integrates two diodes in a compact form factor, supporting highdensity PCB layouts. lts miniature sOT-323 package is compatible with automated assembly processes, and the tape and reel packaging meets mass production requirements. Compliant with RoHs standards, this diode is ideal for high-speed rectification, clamping, and logic control circuits in consumer electronics, communication devices, and power management modules.


    INFORMATION

    Category
    Mfr
    Series
    -
    Packaging
    Tape & Reel (TR)
    Cut Tape (CT)
    Digi-Reel®
    Part Status
    Active
    Technology
    Voltage - DC Reverse (Vr) (Max)
    75 V
    Current - Average Rectified (Io)
    150mA
    Voltage - Forward (Vf) (Max) @ If
    1.25 V @ 150 mA
    Speed
    Small Signal =< 200mA (Io), Any Speed
    Reverse Recovery Time (trr)
    4 ns
    Current - Reverse Leakage @ Vr
    1 µA @ 75 V
    Capacitance @ Vr, F
    2pF @ 0V, 1MHz
    Grade
    -
    Qualification
    -
    Mounting Type
    Package / Case
    Supplier Device Package
    SOT-323
    Operating Temperature - Junction
    -55°C ~ 150°C

    Drawing


    Our advantage :

    • High quality products --- our offers are 100% new and original, ROHS
    • Competitive price --- good Purchase channels with good price.
    • Professional service --- strict quality testing before the shipment, and perfect after-sales service after the purchase.
    • Adequate inventory --- With the support of our strong Purchasing team,
    • Fast delivery --- we will ship the goods within 1-3 working days after the payment confirmed.

    be sure to meet your need for all kinds of components. ^_^


    Product List
    Supply a Series of Electronic Components, full range of semiconductors, active & passive Components.We can help you to get all for bom of the PCB,IN a word, you can get one-stop solution here,


    The offers including:
    Integrated Circuit, Memory ICs, Diode, Transistor , Capacitor, Resistor, Varistor, Fuse, Trimmer & Potentiometer, Transformer, Battery, Cable, Relay, Switch, Connector, Terminal Block, Crystal & Oscillator, Inductor, Sensor, Transformer, IGBT Driver, LED,LCD, Convertor, PCB (Printed Circuit Board),PCBA (PCB Assembly)

    Strong in Brand:
    Microchip, MAX, AD, TI, ATMEL, ST, ON, NS, Intersil, Winbond, Vishay, ISSI, Infineon, NEC, FAIRCHILD, OMRON,YAGEO, TDK, etc

    Quality BAS16W 100V 200mA Switching Diode with 4ns Reverse Recovery Dual Series Configuration SOT-323 Package and Tape & Reel Packaging for High-Speed Circuit Design for sale
