Products of features
Nanfengwang cage has a strong ability of anti-wind,anti-current and
anti-wave. It's made of new material HDPE pipe,making the cage have
a long life. The cage capacity is large and makes a high survival
rate.
1. Wide range of applications, it can be set in the depth of water
from -6m to 50m.
2.Strong ability of wind resistance, can defend against the
typhoon,the maximum is 12 grade.Strong ability of wave resistance
to 7m,strong ability of current resistance to 1.2m/s.
3.Aquaculture capacity,the living space and growing space are
large.
4.The cage has a long life, the cage frame can be used over 15
years.
5.The net can be replaced easily.
6.Material is a marine special HDPE pipe,which is high
strength,high toughness,anti-oxidant and anti-aging.
Technical specifications
HDPE round floating cage frame specificaitons
| Circumference(M) | Diameter of floating pipe(MM) | Diameter of handrial pipe(MM) | Diameter of stand pipe(MM) |
| 30 | 200mm | 90mm | 110mm |
| 40 | 200mm/250mm | 90mm/110mm | 110mm/125mm |
| 50 | 250mm | 110mm | 125mm |
| 60 | 250mm/315mm | 110mm | 125mm |
| 70 | 315mm | 110mm/125mm | 125mm |
| 80 | 315mm | 110mm/125mm | -- |
| 90 | 350mm | 125mm | -- |
| 100 | 350mm/400mm | 125mm | -- |
| 120 | 350mm/400mm | 125mm | -- |
| 150 | 350mm/400mm | 125mm | -- |
| 200 | 400mm | 125mm | -- |
HDPE square floating cage frame specificaitons
| L*W(M) | Diameter of floating pipe(MM) | Diameter of handrial pipe(MM) | Diameter of stand pipe(MM) |
| 3m * 3m | 200mm | 90mm | 110mm |
| 4m * 4m | 200mm | 90mm | 110mm |
| 5m * 5m | 200mm | 90mm | 110mm |
| 6m * 6m | 200mm/250mm | 90mm/110mm | 110mm/125mm |
| 7m * 7m | 250mm/315mm | 110mm | 125mm |
| 8m * 8m | 250mm/315mm | 110mm | 125mm |
| 9m * 9m | 250mm/315mm | 110mm | 125mm |
| 10m * 10m | 315mm | 110mm | 125mm |
| 12m * 12m | 315mm/350mm | 110mm/125mm | 125mm/-- |
| 15m * 15m | 315mm/350mm | 110mm/125mm | 125mm/-- |
| 20m * 20m | 350mm/400mm | 125mm | -- |
| 30m * 30m | 350mm/400mm | 125mm | -- |
Mooring system
Our mooring system is "Grid"system in the deep sea or fresh water,the "Grid"system is made by the ropes and shackles, the cages are in the grid and fixed by ropes.Such the cages are united as one group,
one cage moves,other cages all move,they are interrelated and mutual restraint to avoid destruction accidents caused by
collisions between different cages even in the bad sea condition.
Why
us?
1. Production capacity up to 50000 ton each year!
2. High quality and reasonable design ensure the longlife time of
the cage.
3. After sale service make us to be your best choice.
FAQ:
Finish the business with us, you should do as following:
step 1: Tell us your requirements,involved some
parameters:shape,diameter
step 2: If you don't have specific parameters or your are not
professional in fish farming cage,you can send us some picture of
your cage.
step 3: We will try our best to give you the best suitable size for
you.
step 4: If we have confirmed the cage,we will give you a quotation.
step 5: If you agree with our price,we will make a confirmation
with you about some specific parameters.
step 6: We will pack the fish farming cage then send to you.
