High-Performance 16-Port Ruijie Switch With 10G Uplink & Flexible
Stacking For SMBs
The Ruijie RG-PF2920-16GT2XS is a next-generation 16-port Gigabit
Ethernet switch designed for small and medium businesses (SMBs),
enterprise branch offices, and campus networks. Featuring 2x 10G
SFP+ uplink ports and Flexible Stacking technology, this
high-performance switch ensures scalable bandwidth, seamless
expansion, and simplified network management.
Key Features & Benefits
16x Gigabit Copper Ports + 2x 10G SFP+ Uplinks – Delivers
high-speed connectivity for workstations, IP cameras, and servers,
with 10G fiber uplinks for backbone aggregation.
Flexible Stacking (Up to 8 Units) – Combine multiple switches into
a single logical device for easier management and higher
redundancy.
Advanced QoS & Traffic Prioritization – Ensures smooth performance
for VoIP, video conferencing, and critical applications.
Enterprise-Grade Security – Supports 802.1X authentication, ACLs,
and port security to prevent unauthorized access.
Energy-Efficient Design – Complies with IEEE 802.3az
(Energy-Efficient Ethernet), reducing power consumption by up to
30%.
Technical Specifications
| Model | Ruijie RG-PF2920-16GT2XS |
|---|
| Ports | 16x 10/100/1000BASE-T, 2x 10G SFP+ (shared with last 2 RJ45) |
| Switching Capacity | 256 Gbps |
| Forwarding Rate | 95.2 Mpps |
| Stacking Support | Yes (up to 8 units) |
| Security Features | 802.1X, ACL, Port Security, DHCP Snooping |
| QoS | 8 priority queues, L2/L3/L4 traffic classification |
| Power Consumption | <18W (typical) |
| Dimensions | 440 x 220 x 44 mm (Rack-mountable) |
Why Choose This Ruijie Switch?
Ideal for growing businesses needing reliable, high-speed
networking, the RG-PF2920-16GT2XS offers future-proof 10G uplinks,
simplified stacking, and robust security—all in a cost-effective
package. Whether deploying in office networks, surveillance
systems, or campus environments, this switch ensures low latency,
high throughput, and easy scalability.
Upgrade your network with Ruijie’s advanced switching technology
today!
