Electrical Insulation Epoxy Resin and Liquid Mold Electrical Insulation Epoxy Resin for Medium&high Voltage Transformer

  • Product Details
  • Company Profile

Electrical Insulation Epoxy Resin and Liquid Mold Electrical Insulation Epoxy Resin for Medium&high Voltage Transformer

Product Description

Bi-component alicyclic saturated structure epoxy resin system /liquid can be used to the processes of APG& Conventional casting process under vacuum,Excellent UV resistance &heat shock resistance Excellent environmental performance and mechanical properties.

Epoxy resin
LE-9516
100pbw
Hardener
LH-9516
100pbw
Filling
Silica flour (SIO2)
300-350pbw
Color paste
LC-series
3pbw
Process parameter
APG
Vacuum process
Mix temperature
40℃/1-2 hours
60℃/1-2 hours
Feeding process
Pressure (0.5-5bar)
Vacuum
mold temperature
130-150℃
80-100℃
Detailed Images
Related Products
Our Company

Shanghai Wenyou industry co., Ltd. Is located in Fengxian District,Shanghai ,China.It is a professional company engaged in the manufacturing,R&D,sales of the epoxy resin,curing agent and other Products.Our products include epoxy resin,Flame retardant resin,curing agent,outdoor modifier,toughening agent ,epoxy paste,demoulding agent and filler,they are not only sold in china,but also exported to Europe,Southeast Asia,Middle East region and Russia and the other CIS countries.

The company has passed management system of ISO9001 and ISO14001,the European Union”SGS”,and also the United States UL certification.The products comply with ROHS and REACH safety regulations,which are widely used in indoor and outdoor 10-1100KV high voltage electrical insulation,such as:high voltage switch insulation parts,mutual inductors,transformers,reactors,etc.All kinds of electronic components and products can be applied to different application process and molding equipment,such as vacuum pressure casting technology and APG technology.The Quality of our products is the award-winning in the market,and also established a good reputation for our company.

Wenyou is based on china,serving for global electricity,providing stable products and high quality service to all of the world.

Certifications
Application

Our company products be used for Medium&high voltage insulation switch parts.

Our company products be used for Electrical insulators.

Our company products be used for transformers

Packing & Delivery

Fully automated packaging.

Put up the products to ensure products safety.

Our copany products are loading up waiting to be transported to port.

FAQ

1.Do you think what is your factory's biggest adventage?
A:Technology is our core competitiveness
2.Can your factory supply samples with free if we need?
A: Yes,we can .
3.What is your product's MOQ?
A:We haven't exact MOQ for our products ,if you just need 200 KG we also sell .your satisfaction is our biggest pursuit.
