    Xrido Hydraulic Gantry Shear 200-800T Scrap Metal Cutting Machine

    Ask Lasest Price
    Brand Name : Xrido
    Model Number : Customizable
    Certification : CE ISO
    Delivery Time : 5-30 word days
    • Product Details
    • Company Profile

    Xrido Hydraulic Gantry Shear 200-800T Scrap Metal Cutting Machine

    Products Description

    As a hydraulic guillotine shear system, it processes mixed scrap including stainless steel plates, metal compacts, rods and structural parts by cold-cutting them into standardized charge-ready fragments without thermal deformation.‌
    The gantry-type shearing machine handles bulk metal recycling tasks, capable of sizing steel plates, pipes, pressed blocks and light alloy components into manageable pieces through high-force hydraulic cutting mechanisms.‌



    Technical Parameters
    ModelShearing force(Ton)Pressure-Plate-Force(Ton)Length of knife edge(mm)Shear specification(mm)Motor Power(kw)
    XRD-6363Ton16Ton600mm3030,40407.5KW
    XRD-100100Ton16Ton800mm4040,454511KW
    XRD-120120Ton16Ton1000mm4545,555515KW
    XRD-160160Ton16Ton1200mm5555,656518.5KW
    XRD-200200Ton16Ton1400mm6565,707022KW
    XRD-250250Ton16Ton1600mm7070,808030KW
    XRD-315315Ton42Ton1600mm8080,909037KW
    XRD-400400Ton42Ton1800mm9090,10010044KW
    XRD-500500Ton42Ton1800mm100*10044KW



    Product Details
    1,Through automatic feeding box,after the material is grabbed to the upper material box, the waste is automatically sent to the cutting edge by the conveyor belt, and the feeding speed can be adjusted by the speed regulating motor.
    2,The two sides of the material box are equipped with side extrusion oil cylinders. If the large-scale waste materials, such as scrapped cars, cannot pass the cutting edge of the gantry shear, they can be squeezed and reduced by the side extrusion oil cylinder, and then sent to the cutting edge through the conveyor to cut off.

    Product Features
    01,The shearing ability is large. The shearing ability is large. The shear angle reaches to 12 degrees, and the shearing ability is increased by more than 20% compared with the normal shear angle (9 degrees).
    02,The main machine of adopts steel plate welding, paint after rust removal The main machine of adopts steel plate welding, paint after rust removal (shot blasting rust removal), and sharp edge burr removal. The main machine has straight weld, regular shape, high mechanical strength and good appearance quality.
    0,3In view of the wear characteristics of the relevant parts of the shearing machine In view of the wear characteristics of the relevant parts of the shearing machine, high strength wear-resistant alloy steel plates are installed on the inner walls of the pressing device, gantry frame and pushing box, which effectively prolongs equipment service life.
    Applicable Materials
    Thin steel material, steel bar, steel plate, nickel plate, steel plate, round steel, steel pipe, scrap copper, scrap iron, light metal structural parts,stainless steel, metal pressing block, automobile body, aluminum alloy, copper, iron filings, steel wire, metal pressing block and other scrap metal cold cutting short

    Advantages and Features
    ① In view of the wear characteristics of the relevant parts of the shearing machine, high-strength wear-resistant alloy steel plates are installed on the inner wall of the pressing device, gantry, and push box to effectively extend the service life of the equipment.
    ②Independent circulation oil return filtration and cooling unit are adopted, and the oil tank has high and low liquid level alarm functions and oil temperature heating devices. The filtration accuracy is 20 microns, and the cooling system is water cooling.
    ③ The friction pair of the shearing slider guide rail of the equipment is composed of high-strength wear-resistant copper alloy plate and quenched alloy steel plate, which meets the requirements of equipment, harsh use environment, large equipment load, and large friction. The shearing slider guide rail adopts automatic lubrication, and the shearing cylinder automatically lubricates for 10 seconds every 30 shears. The user can also adjust the lubrication time according to needs (touch screen setting). In order to prevent dry friction from damaging the guide rail, the equipment is set with a lubrication oil cut-off automatic shutdown function.
    Quality Xrido Hydraulic Gantry Shear 200-800T Scrap Metal Cutting Machine for sale
