Input signal

TC: JIS C1602:1995 (*1), IEC584:1995 Type J,

K, E, B (*2), R, S, T, N

mV: -100 to 150 mV, -20 to 80 mV

RTD: JIS C1604:1997 (*3), IEC751:1995 Pt100 (3-wire type)

POT: Total resistance 100 Ω to 10 kΩ

Span resistance:

50 % or larger of total resistance

Between input and system: 500 VAC (for single card: 1500 VAC), For 1 minute

Between input channels: 200 VAC, For 1 minute

RTD: ±150 mΩ

POT: ±0.2 %/FS

Reference junction

compensation accuracy

All channels can be set together.

Setting: not available/available (UP/DOWN)

Detection time: 60 s

RTD: ±0.3 Ω/10 °C

POT: ±0.4 %/10 °C

Maximum current

consumption
