    Custom Pre Engineered Steel Warehouse with H-section Beams

    Ask Lasest Price
    Brand Name : YDX
    Model Number : YDX-1S
    Certification : CE ISO SGS
    Price : $35.00-$63.00
    Payment Terms : T/T
    Supply Ability : 10000 tons/month
    Delivery Time : 20-30 works days
    • Product Details
    • Company Profile

    Custom Pre Engineered Steel Warehouse with H-section Beams

    Commercial Pre Engineered Well Surface Treatment Steel Structure Industrial Plant Workshop Custom
    Product Attributes
    AttributeValue
    Column And BeamWelded H-section
    KeyVersatility
    Product TypeBuilding Construction
    Roof PurlinC/Z section Purlin
    RoofingSandwich Panel. Single Steel Sheet
    HighlightPainted Steel Structure Warehouse
    Product Description
    Our commercial pre-engineered steel structures offer superior strength and versatility for industrial applications. The high strength-to-weight ratio of steel makes these structures exceptionally strong while remaining lightweight compared to traditional construction materials like concrete and wood.
    Steel Structure Features
    • High strength-to-weight ratio for superior structural integrity
    • Ductile properties absorb energy effectively, ideal for earthquake-prone areas
    • Customizable shapes, dimensions, and thicknesses through hot or cold rolling processes
    • Lightweight construction without compromising strength
    Applications
    Our steel structures are ideal for various industrial applications including:
    • Light frame steel construction hangars
    • Prefabricated steel structure factory buildings
    • Industrial workshops and warehouses
    Pre-engineered steel buildings utilize modern technology where complete designs are factory-made, with components assembled on-site using bolt connections (no welding required). This efficient design can be up to 30% lighter than conventional steel buildings, resulting in material savings and cost efficiency.
    Specifications
    ComponentSpecification
    Main Steel Frame
    Material: Q345B (S355JR) or Q235B(S235JR)/ Welded/Hot Rolled H section steel
    Surface: Hot Dip Galvanized or Painted
    Connection: All Bolts Connection
    Supporting System
    Roof Purlin: C or Z Section Steel, Q235B
    Wall Purlin: C or Z Section Steel, Q235B
    Bracing: Steel Rod, Q235B
    Cross Support: Steel Rod, Q235B
    Column Support: Angle Steel; Steel Rod; Q235B
    Angle Brace: Angle steel, Q235B
    Tie Bar: Steel Pipe, Q235B
    Roof & Wall System
    Single Colorful Corrugated Steel Sheet (Thickness: 0.3-0.8mm)
    Sandwich Panel with EPS, Rock Wool, Fiberglass, PU (Thickness: 50-150mm)
    Accessories
    Door: Sliding; Rolled Up Door (Manual/Auto)
    Window: Aluminum Alloy; PVC
    Downspout: PVC pipe
    Gutter: Galvanized Steel Sheet; Stainless Steel
    Ventilator: Stainless Steel Turbine Ventilator
    Skylight Belt: FRP or PC semi-transparent Skylight Belt
    Flash: Color Steel Sheet
    Fittings: Anchor Bolt; High Strength Bolt; Standard Bolt, Self-tapping nail etc
    Product Images
    Quality Custom Pre Engineered Steel Warehouse with H-section Beams for sale
