    Q355 Q235 Steel Structure Warehouse with Sandwich Panel Walls

    Ask Lasest Price
    Brand Name : YDX
    Model Number : YDX-00
    Certification : CE ISO SGS
    Price : $35.00-$65.00
    Payment Terms : T/T
    Supply Ability : 10000 tons/month
    Delivery Time : 20-30 works days
    • Product Details
    • Company Profile

    Q355 Q235 Steel Structure Warehouse with Sandwich Panel Walls

    Prefabricated Steel Structure Warehouse for maize processing mill

    Prefabricated steel warehouse manufacturers in china

    Metal warehouse structures&Metallic structure for warehouse

    Prefabricated steel warehouse manufacturers in china Project Description:

    Size:With the size of 38m*24m*8m, the South Africa steel warehouse project used the structural steel as the main steel frame with the corrugated steel sheet to give the whole building a safety structure and beautiful look.

    Our engineer installation team helped the client to build up the steel warehouse within 30 days.
    1. Main steel structure: Welded H section steel column with anti-rust painting and Anti-corrosive painted;
    2. Roof frame truss: Galvanized C section steel;
    3. Roof maintenance: 0.5mm or 0.6mm Color steel corrugated sheet
    4. Wall maintenance:0.5mm or 0.6mm Color steel corrugated sheet

    5. Tie bar: Φ20 Round steel;
    6. Brace: Round steel;
    7. Horizontally transverse braces : Round steel;
    8. Knee bracing: Q235B Angle steel;
    9. Covering for roof and wall flashing :0.5MM Color steel sheet matching the color of roof and wall;
    10. Gutter kinds: Color steel sheet or stainless steel gutter;
    11: Door: Shutter rolling door;

    12. Project time:2010

    13. Color chart: RAL 9002 Grey white, RAL 3001 Signal red, RAL 9003 Signal white, Blue.

    14. Construction company: Qingdao Yidongxiang steel structure co., ltd.


    Steel structure warehouse composition
    1. column and beamMaterial Q355 box or H-shaped steel (painted or galvanized)
    2. Steel structure sprayinggalvanized or painted
    3. wall&roof purlinC or Z section steel
    4. wall&roof panelcolorful corrugated steel sheet ,sandwich panels with EPS, rock wool, fiber glass, PU etc.
    5.supportsteel angle, steel pipe, steel round
    6.guttersteel sheet or galvanized steel sheet
    7.downpipepvc pipe
    8.doorsliding sandwich panel door or rolling metal door
    9.windowPVC or aluminum alloy windows
    10.accessoryanchor bolt,high strengthen bolt, normal Bolt, skylight Belts, ventilators, etc
    11.UseOur steel structure building have many applications and uses. Workshop, warehouse, office building, multi-story building, hangar,garage, livestock farm,poultry farm ,ect.
    12.Advantage1.Low cost, convenient.
    2.Easy assembly and disassembly many times without damage.
    3.Widely used in construction site, office building , etc.
    4.Good environmental protection.

    Standard

    SGS,ISO, GB,CE

    Material

    Q345B(S235JR&S355JR)

    Dimensions

    According to the clients requirements

    FOB Price

    US $ 30 - 100 / Square Meter

    Port of loading

    Qingdao

    Minimum Order(ton)

    20 tons

    Payment Terms

    L/C,T/T

    Quality Control

    The third party ,SGS,ASIA INSPECTION all accept

    Surface Treatment

    Shot blasting with anti rust paint or hot dip galvanize

    Delivery Term

    Within 30 days after receiving deposit

    Packaging

    According yours requirement, usually bundle with steel strip

    Our Experience

    Have exported more than 25 years.

    Roof ,Wall material

    Color steel sheet or PU,EPS, Rock Wool sandwich panel

    Window

    PVC or Aluminum Alloy

    Main steel Column and Beam

    H section ,I section or Galvanized

    Roof Purlin

    C-Section and Z-section

    Surface

    2 primer and 1 finished paint

    Local Climate

    1.wind speed 2.Rain load 3.Snow load 4.Earthquake grade if have etc.

    Crane parameter

    If need crane beam, parameter is in need.

    Package

    standard packing or as request

    Load in

    20GP, 40GP, 40OT
