    Large-Scale Automatic Docking Production Line Efficient Weighing Machine

    Ask Lasest Price
    Brand Name : SHANAN
    Model Number : SACW500
    Certification : ce
    • Product Details
    • Company Profile

    Large-Scale Automatic Docking Production Line Efficient Weighing Machine

    Large-Scale Automatic Docking Production Line Efficient Weighing Machine
    Automatic weighing machine overview Weighing machine side view Production line integration Control system interface Weighing mechanism detail Machine operation view Industrial weighing application
    Technical Specifications
    Product ModelSACW-120A
    Transfer Speed20~60 m/min
    Power SupplyAC220V±10% 50HZ (60HZ)
    Maximum Speed180 pcs/min
    Rated Power0.15KW
    Weighing Conveyor Belt Size250mm(L) * 120mm(W)
    Single Weighing Range1.5-200g
    Elimination MethodBlow-out
    Weighing Accuracy Range±0.05g ~ ±0.1g
    Control SystemHigh speed A/D sampling controller
    Minimum Scale0.01g
    Preset Product Number2000 pcs
    Inspection Item SizeLength: 30-150mm, Width: 30-90mm, Height: 10-100mm
    Machine Size900mm(L) * 500mm(W) * 1250mm(H)
    Operation DirectionFacing the machine, left to right
    External Air Supply0.6-1 Mpa
    Air Pressure InterfaceΦ8mm
    Working EnvironmentTemperature: 0°C~40°C, Humidity: 30%~95%
    Body MaterialStainless steel 304 polished
    Operation Screen DisplayChinese, English, Turkish, Spanish, etc.
    Other Standard EquipmentWindshield (colorless and transparent), calibration weight
    Height of Belt Surface from Ground650mm-750mm (can be customized)
    Protection LevelProtection level conforms to IP-55 international standard
    Note: According to the different dimensions of the tested product and the working environment in which the equipment is running, the accuracy of the speedometer is slightly different.
