Vacuum Homogenizer Machine Liquid Soap Making Machine /Shampoo
Chemical Machinery Agitator Cosmetics Emulsifying
Introuduction:
The machine is suitable for the production of various kinds of
paste, cream products in cosmetic factory and pharmaceutical
factory.
1, It's used for produce the cream, lotion, paste, ointment, paste,
conditioner, etc. Complex scraping board blending oar is suitable to every kind of
complicated recipe and achieve optimizing effect;
2, Polytetrafluroethylene scraping board cater to body of blending
groove and scrape out viscosity material on boiler wall;
3, Homogenizer is installed on boiler bottom to increase motor power more thoroughly and strongly. During few
production, it can exert homogenizing effect fully;
4,Mightiness balance isotactic curve rotor is matched with stator
with corresponding structure to realize liquid high-capability
cut,rubbing,centrifugal to make sure exquisite and slick cream;
boiler body and pipe surface mirror polishing 300EMSH (sanitation grade) accords with Daily Chemical and GMP regulation.
5, Customer can choose frequency conversion timing homogenizer and
highest rotate speed is 5500 r/min.
Specifications:
| Model | Main pot | Emulsifying motor (kw) | Emulsifying motor (r/min) | Mixing motor(kw) | Dimension(L*W*H) | Total power steam/Electric heating(kw) | Limit power (Mpa) |
| RHJ-A300 | 300L | 6.5-8 | 1440/2880 | 3 | 1580*2800*2800mm | 12/38 | -0.085 |
| RHJ-A500 | 500L | 6.5-8 | 1440/2880 | 3 | 1780*3050*2950mm | 15/50 | -0.085 |
| RHJ-A800 | 800L | 9-11 | 1440/2880 | 4 | 1850*3250*3150mm | 20/65 | -0.085 |
| RHJ-A1000 | 1000L | 9-11 | 1440/2880 | 5.5 | 2100*3400*3650mm | 29/75 | -0.08 |
| RHJ-A2000 | 2000L | 11-14 | 1440/2880 | 5.5 | 2750*3950*4300mm | 38/92 | -0.08 |
| RHJ-A3000 | 3000L | 15-18 | 1440/2880 | 7.5 | 3000*4300*4500mm | 43/120 | -0.08 |
Shear Forces and Molecule Interaction: High shear homogenizers use
a rotor-stator system that generates high shear rates, which are
crucial for breaking down the droplets of one liquid within
another. The intense mechanical shear in the precision gap between
the rotor and stator subjects the oil and water molecules to high
velocity differentials and turbulent flow, which helps in breaking
down the droplets and creating a more uniform mixture
.
Reduction of Droplet Size: The high shear forces generated by the
homogenizer reduce the size of oil droplets in an oil-in-water
emulsion. This is important because smaller droplets have a larger
surface area, which can improve the stability of the emulsion by
reducing the rate of coalescence and separation
.
Surface Activity and Emulsifier Adsorption: High-pressure
homogenization not only reduces droplet size but also increases the
surface activity of emulsifying molecules. This can improve the
efficiency of the product, such as its coating ability or
penetration action. Emulsifiers, which can be proteins or low
molecular weight compounds like lecithins and monoglycerides, are
adsorbed at the oil-water interface. These emulsifiers lower the
surface tension between the oil and water interfaces formed during
emulsification and form a protective layer around the dispersed
particles, which structurally stabilizes the emulsion
.
Enhanced Stability: The use of high shear homogenization leads to a
significant rearrangement of the oil-water interface, where
proteins and low molecular weight emulsifiers play a crucial role
in the production and stabilization of emulsions. They prevent the
droplets from coalescing and help maintain the stability of the
emulsion
.
Uniform Distribution: The goal of high shear homogenization is to
create a uniform mixture with a single continuous phase. This is
achieved by evenly sizing and distributing the liquid droplets,
which represent the dispersed phase, within the continuous phase.
The high shear mixer continually breaks down these droplets to
prevent natural separation, which is particularly important in
immiscible liquids like oil and water
To clean a vacuum emulsifying machine, follow these steps: First,
disconnect the power supply and let the machine cool down. Remove
any residual product from the mixing chamber and blades. Use a mild
detergent and warm water to clean the interior surfaces, ensuring
no product residue remains. Rinse thoroughly with clean water. Wipe
down the exterior with a damp cloth. Regularly inspect and replace
any worn seals or gaskets to maintain a vacuum seal. Always refer
to the manufacturer's guidelines for specific cleaning
instructions.
