Product Description:
For most industrial applications, Welded Bar Grating is an
affordable option. It is created using forge welding techniques
that connect rectangular bearing bars and drawn cross bars together
in a durable and long-lasting way even under the most difficult
conditions.
Welded Bar Grating is obtainable in two different types: type “W”
Welded Steel or type “WS” Welded Stainless Steel. The width of the
bearing bar spacing ranges from 19/16″ (1-3/16″) to 7/16″, with
cross bars that are either 4″ or 2″ separated. The Welded Bar
Grating is available with a smooth plain surface and optional
serrated surface.
The spacing between bearing bars is an important factor to consider
when choosing Welded Bar Grating. The greater the bearing bar
spacing, the more cost-effective the bar grating becomes. However,
bear in mind that the bearing bar spacing should not be too far
apart, as it may cause issues with foot traffic and possible items
getting stuck in the larger gaps. The cross bars add to the
grating's strength and longevity, making it an excellent option for
most industrial needs.
The standard design of Welded Bar Grating has a plain surface, but
the serrated surface option is also available. The serrated surface
provides additional traction, which is beneficial if your walkway
or flooring is exposed to wet or slippery conditions. The Welded
Bar Grating's serration helps to increase traction, which lowers
the risk of accidents, especially in areas where employee safety is
a concern.
Features:
.
Technical Parameters:
| Advantage | Durability |
| Application | Flooring, Walkway, Platform, Drainage Cover, Trench Cover, Stair
Treads |
| Bearing Bar Spacing | 30mm, 40mm, 60mm |
| Standard | Customized-Made, ISO9001, Q235 |
| Surface Treatment | Hot - Dipped Galvanized |
| Coating | HOT GALVANIZED, PVC, ETC |
| Hole Shape | Square |
| Cross Bar Size | 6mm, 8mm |
| Bearing Bar | 25x3 |
| Payment | TT |
Applications:
Bar Grating is a versatile material that finds utility across
several domains of applications. Due to its exceptional resistance
to corrosion, it is an excellent choice for use in an assortment of
transportation and construction-related applications.
One of the primary benefits of Bar Grating is its sturdy nature,
which makes it suitable for use in high-traffic areas or areas
subjected to heavy loads. This aspect makes it an ideal material
for high-stress applications that demand resilience and strength.
Moreover, Bar Grating is a highly customizable material. As a
result, it can be fabricated into various sizes and shapes to meet
specific customer requirements. This versatility lends itself well
to innovative designs and architecture.
Finally, the cost-effectiveness of Bar Grating also makes it an
attractive option. It is a practical alternative to other
high-strength materials, making it an excellent choice for
budget-conscious projects.
Customization:
Brand Name: Yuhan
Model Number: Yuhan-SG-003
Place of Origin: China
Bearing Bar Spacing: 30mm, 40mm, 60mm
Coating: HOT GALVANIZED, PVC, ETC
Cross Bar Size: 6mm, 8mm
Bearing Bar: 25x3
Payment: TT
We also offer customization services for Aluminum Grating. Contact
us for more details.
Packing and Shipping:
Product Packaging:
The steel grating product will be securely packed in wooden pallets
to ensure safe transportation to the desired destination. The
pallets will be wrapped with shrink-wrap to prevent any damage
during transit.
Shipping:
The steel grating product will be shipped via a freight carrier
that can accommodate the size and weight of the product. The
shipping cost will depend on the destination and delivery time
required. Please contact our customer service team for shipping
quotes and further assistance.
